/ / / / / / ГИДРОЛИНИЯ (PPC ТРУБЫ) (/)
Запчасти Komatsu PW110R-1 ГИДРОЛИНИЯ (PPC ТРУБЫ) (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ
13
a
c
b
b
a
c
A
19
B
C
D
20
21
22
18
23
3
2
1
3
11
10
12
35
36
14
15
7
24
8
17
9
16
36
35
27
2
1
4
17
26
25
32
3
34
30
29
6
33
18
30
5
27
6
31
5
28
7
4
3
1
21D-09-51190
UNION
2
21D-09-69910
O-RING
3
22E-09-12190
HOSE
4
21D-09-52520
TEE
5
21D-09-51630
ELBOW
6
21D-09-69910
O-RING
7
21D-09-97310
HOSE
8
21D-09-51190
UNION
9
21D-09-69910
O-RING
10
21D-09-58350
TEE
11
21D-09-69910
O-RING
12
21D-09-66810
UNION
13
21D-60-17310
ACCUMULATOR
14
21D-09-53530
UNION
15
21D-60-17120
VALVE
16
21D-09-51620
ELBOW
17
22E-09-12190
HOSE
18
226-09-11180
HOSE
19
21D-09-55670
ELBOW
20
21D-09-52520
TEE
21
21D-09-51190
UNION
22
21D-09-69910
O-RING
23
22E-62-11430
REDUCTION
24
226-60-18210
SUPPORT
25
01010-51020
BOLT
26
01643-31032
WASHER
27
226-60-18700
SOLENOID VALVE, ASSY.
28
21D-60-18510
VALVE
29
21D-60-18520
KIT, GASKET
30
226-60-18110
COIL
31
21D-60-18530
VALVE
32
21D-60-18520
KIT, GASKET
33
01010-50816
BOLT
34
01643-30823
WASHER
35
21D-09-54720
PLUG
36
21D-09-73160
GASKET
