Запчасти Komatsu PW110R-1 ГИДРОЛИНИЯ ЗАДН. ОТВАЛ УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ
30
31
29
29
28
26
4
26
31
5
27
13
8
27
29
29
25
25
30
7
28
4
29
12
23
6
10
7
22
11
29
44
24
47
29
16
21
19
22
46
20
45
18
20
19
17
18
14
13
15
9
8
44
30
34
32
33
31
38
37
43
3
1
35
2
40
39
42
41
36
b
b
b
c
c
c
a
a
1
226-09-12670
UNION
2
21D-09-69910
O-RING
3
21D-09-69670
O-RING
4
226-09-12140
ELBOW
5
21D-09-69670
O-RING
6
226-09-12270
TEE
7
21D-09-69670
O-RING
8
226-09-11280
HOSE
9
21D-09-69670
O-RING
10
226-09-12680
UNION
11
21D-09-69970
O-RING
12
21D-09-69670
O-RING
13
22E-09-15120
HOSE
14
21D-09-69670
O-RING
15
226-62-13290
PIPE
16
226-62-13310
PIPE
17
226-62-13320
PIPE
18
21D-09-68220
CLAMP
19
01016-50830
BOLT
20
01643-30823
WASHER
21
226-09-12380
TEE
22
21D-09-69670
O-RING
23
226-62-13330
PIPE
24
226-62-13340
PIPE
25
21D-09-68180
HOSE-CLAMP
26
01010-50630
BOLT
27
01643-30623
WASHER
28
226-09-12150
ELBOW
29
21D-09-69670
O-RING
30
22E-09-12780
HOSE
31
22E-09-12480
HOSE
32
226-09-12750
ELBOW
33
21D-09-69910
O-RING
34
21D-09-69670
O-RING
35
21D-60-17200
VALVE, ASSY.
36
21D-60-17250
KIT, GASKET
37
226-62-13350
UNION
38
21D-09-69910
O-RING
39
226-62-13360
UNION
40
21D-09-69910
O-RING
41
21D-09-69770
O-RING
42
226-09-12120
ELBOW
43
21D-09-69770
O-RING
44
22E-09-15110
HOSE
45
226-09-12750
ELBOW
46
21D-09-69910
O-RING
47
21D-09-69670
O-RING
