/ / / / / / ЦИЛИНДР РУКОЯТИ(ВНУТР. ЧАСТИ) (ДЛЯ MONO СТРЕЛА)
Запчасти Komatsu PW128UU-1 ЦИЛИНДР РУКОЯТИ(ВНУТР. ЧАСТИ) (ДЛЯ MONO СТРЕЛА) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
3
4
5
6
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
22
23
24
25
25
25A
25B
26
27
27
27
28
28
28
29
29
29A
29B
29C
29D
30
31
32
32
33
34
35
35
36
37
38
39
40
41
42
G1
21J-63-X2420
CYLINDER GROUP
|G1
21J-63-X2220
CYLINDER GROUP
|1
202-63-02721
CYLINDER ASS'Y,ARM
|1
202-63-02322
CYLINDER ASS'Y,ARM
1
202-63-65141
CYLINDER,ARM
|1
202-63-64342
CYLINDER,ARM
2
707-76-70240
BUSHING
3
07145-00070
SEAL,DUST (KIT)
4
707-71-32530
COLLAR
|4
707-71-32510
COLLAR
5
07000-15105
O-RING (KIT)
|5
07000-15110
O-RING (KIT)
6
707-35-91150
RING,BACK-UP (KIT)
|6
07001-05110
RING,BACK-UP (KIT)
7
707-27-11971
HEAD,CYLINDER
|7
707-27-11670
HEAD,CYLINDER
8
707-52-90500
BUSHING
9
707-51-75030
PACKING,ROD (KIT)
10
707-51-75630
RING,BUFFER (KIT)
11
07000-15105
O-RING (KIT)
|11
07000-15110
O-RING (KIT)
12
707-35-91150
RING,BACK-UP (KIT)
|12
07001-05110
RING,BACK-UP (KIT)
13
144-63-94170
SEAL,DUST (KIT)
14
07179-13089
RING,SNAP
15
01010-81670
BOLT
16
01643-51645
WASHER
17
202-63-65120
ROD
|17
202-63-64321
ROD
18
707-71-60200
PLUNGER
19
04260-00635
BALL
20
707-71-91270
CAP
21
707-76-70240
BUSHING
22
07145-00070
SEAL,DUST (KIT)
23
707-71-60870
PLUNGER
|23
707-71-60830
PLUNGER
24
707-40-11470
RETAINER
25
707-36-11661
PISTON
|25
707-36-11510
PISTON
25A
07000-15070
O-RING (KIT)
25B
707-35-90360
RING,BACK-UP (KIT)
26
707-44-11280
RING,PISTON (KIT)
27
707-39-11510
RING,WEAR (KIT)
28
707-44-11920
RING
29
01310-01216
SCREW
|29
07165-15860
NUT,NYLON
29A
707-83-13010
VALVE
29B
07750-01628
SPRING
29C
707-87-14070
PLUG
29D
07002-12034
O-RING (KIT)
30
202-63-65170
TUBE
|30
202-63-64371
TUBE
31
707-87-13570
ELBOW
32
07000-13025
O-RING (KIT)
33
01010-80850
BOLT
34
01010-80855
BOLT
35
01643-50823
WASHER
36
707-88-95360
BAND
37
707-88-95510
BRACKET
38
01010-81035
BOLT
39
01643-51032
WASHER
40
07283-22236
CLIP
41
01599-01011
NUT
42
01643-31032
WASHER
KIT
707-99-44230
SERVICE KIT,ARM CYLINDER
|KIT
707-99-44200
SERVICE KIT,ARM CYLINDER
