Запчасти Komatsu PW130-6K ГИДР. БАК. ГИДРАВЛИКА
1
1
2
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
22
23
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
|1
20E-60-K1300
TANK ASS'Y
1
TANK
2
203-60-31160
TUBE
3
203-60-31100
ELBOW ASS'Y
4
20E-60-K1240
PLATE ASS'Y
5
07000-05195
O-RING
6
01010-51265
BOLT
7
01643-31232
WASHER
8
07063-01100
ELEMENT
9
203-60-52260
STRAINER
10
203-60-52250
VALVE ASS'Y
11
175-60-27340
SPRING
12
07000-05155
O-RING
13
COVER
14
01010-51225
BOLT
15
01643-31232
WASHER
16
203-60-56250
STRAINER
17
203-60-56270
O-RING
18
20E-60-K1220
ROD
19
12R-60-11230
SPRING
20
07000-05180
O-RING
21
COVER
22
01010-51235
BOLT
23
01643-31232
WASHER
24
205-60-51460
GASKET
25
201-60-12171
FILLER NECK
26
01220-40516
SCREW
27
01601-20513
WASHER
28
201-60-12190
CAP ASS'Y
29
07044-12412
PLUG
30
07002-02434
O-RING
31
07270-00895
TUBE
32
07280-01110
CLAMP
33
08036-01214
CLIP
34
203-60-69150
COVER
35
01010-51220
BOLT
36
01643-31232
WASHER
37
203-06-61561
BRACKET
38
01010-51220
BOLT
39
01643-31232
WASHER
40
01010-51635
BOLT
41
01643-31645
WASHER
