Запчасти Komatsu PW130ES-6K ОБОГРЕВАТЕЛЬ. КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ
1
2
2
2A
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
17
18
18
19
20
21
22
23
24
25
26
26
26
26
26
27
28
29
29
30
31
32
33
34
35
1
20Y-977-K392
HEATER ASS'Y
|1
20Y-977-K391
HEATER ASS'Y
2
01010-81025
BOLT
2A
20Y-970-K760
SPACER
3
01643-31032
WASHER
4
20Y-977-K230
SEAL
5
20Y-977-K240
FILTER ASS'Y
6
20Y-977-K260
ELEMENT
7
20Y-977-K280
NUT
8
01580-10605
NUT
9
01643-30623
WASHER
10
20Y-977-K380
DUCT
11
20Y-977-K310
CABLE
12
20Y-977-K321
CABLE
13
20Y-977-K340
CONTROLLER ASS'Y
|13
20Y-977-K360
KNOB
14
20Y-977-K370
SWITCH
15
01023-10510
SCREW
16
20E-06-K1870
RESISTOR
17
09483-00527
HOSE
18
09483-00518
HOSE
19
421-07-11550
CLIP
20
01010-81230
BOLT
21
01643-31232
WASHER
22
421-07-11550
CLIP
23
01010-81230
BOLT
24
01643-31232
WASHER
25
08034-00536
BAND
26
07281-00259
CLAMP
27
20Y-977-K490
ELBOW
28
203-62-41150
COVER
29
08034-00823
BAND
30
20E-977-K110
ELBOW
31
08034-00519
BAND
32
08034-00823
BAND
33
08034-00536
BAND
34
08036-10610
CLIP
35
08036-02514
CLIP
