/ / / / / / ОСНОВН. КОНСТРУКЦИЯ (КОНСОЛЬН. БЛОК, RHS)
Запчасти Komatsu PW140-7 ОСНОВН. КОНСТРУКЦИЯ (КОНСОЛЬН. БЛОК, RHS) K OPERATORґS ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ
5
11
45
13
21
12
20
8
23
6
22
4
14
1
18
20
3
10
7
36
18
18
16
27
25
9
19
35
15
37
30
25
2
17
39
26
25
35
37
44
38
34
25
29
32
25
28
25
24
33
43
31
25
40
42
41
a
a
1
22U-43-23110
STAY
2
20E-06-31561
WIRING HARNESS
3
22U-43-23120
BRACKET
4
22U-43-23130
STAY
5
22U-06-22290
SWITCH, SWING LOCK
6
20J-43-12180
COVER
7
22U-06-22420
POTENTIOMETER ASSEMBLY
8
22U-06-22470
KNOB
9
08086-20000
SWITCH, STARTING
10
22U-06-22480
PLATE
11
20J-06-11630
SWITCH, QUICK COUPLER
12
20K-06-31750
SWITCH, PARK BRAKE
13
20J-06-11540
SWITCH, WORK LAMP
14
20Y-06-23770
CLIP
15
20Y-06-23920
CLAMP
16
08034-10414
BAND
17
01023-60410
SCREW
18
01023-60512
SCREW
19
01023-10508
SCREW
20
01023-10512
SCREW
21
01601-20513
WASHER
22
01023-60620
SCREW
23
01023-70514
SCREW
24
22U-43-23210
COVER
25
20E-06-31131
SWITCH ASSEMBLY
26
20J-06-11110
PLATE
27
20E-06-31151
HARNESS (PROLIX)
28
20E-06-31161
PROLIX HARNESS
29
421-06-31121
SWITCH
30
20J-06-11120
PLATE
31
08059-00515
CLIP
32
08034-20310
BAND
33
22U-43-23230
COVER
34
20J-43-12231
FRAME
35
01023-60616
SCREW
36
01023-60416
SCREW
37
287-06-16420
BRACKET
38
569-06-61960
RELAY
39
01435-00612
BOLT
40
22U-43-23711
COVER
41
01023-10614
SCREW
42
01643-30623
WASHER
43
08034-20536
BAND
44
01010-D1030
BOLT
45
01643-31032
WASHER
