/ / / / / / OPERATORґS КАБИНА - ПЕРЕДН. ОКНА
Запчасти Komatsu PW148-8 OPERATORґS КАБИНА - ПЕРЕДН. ОКНА K OPERATORґS ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ
11
8
12
16
17
15
13
9
10
5
11
1
3
6
7
19
41
20
12
18
14
4
13
38
35
32
31
2
42
34
37
36
40
39
24
23
22
21
38
30
29
28
35
26
27
25
33
37
36
43
44
46
45
|$1
20G-53-41131
OPERATORґS CAB ASSEMBLY
|$2
20Y-53-00091
WINDOW ASSEMBLY
1
20Y-53-18511
FRAME
2
20Y-53-11520
GLASS
3
20Y-54-51531
SEAL
4
20Y-53-11551
SEAL
5
22B-54-15411
LOCK
6
22B-54-15440
CASE
7
22B-54-15470
KNOB
8
22B-54-15421
LOCK
9
22B-54-15450
CASE
10
22B-54-15480
KNOB
11
01435-40812
BOLT
12
20Y-54-52621
ROLLER
13
20Y-54-52681
ROLLER
14
20Y-53-12330
PIN
15
20Y-54-14590
HANDLE
16
01245-00616
SCREW
17
01643-70623
WASHER
18
20Y-53-12830
BRACKET
19
01245-00816
SCREW
20
01643-70823
WASHER
21
20Y-54-51670
STOPPER
22
20Y-54-51680
STOPPER
23
01252-80616
BOLT
24
01643-70623
WASHER
25
20Y-53-11561
BLOCK ASSEMBLY
26
01245-00816
SCREW
27
01643-70823
WASHER
28
20Y-53-11661
BRACKET
29
01245-00816
SCREW
30
01643-70823
WASHER
31
21J-06-12440
SWITCH
32
01583-11811
NUT
33
20Y-53-11581
BRACKET
34
20Y-53-11641
BRACKET
35
01435-00612
BOLT
36
20Y-54-11611
STOPPER
37
01580-11008
NUT
38
20Y-54-51621
STRIKER
39
01584-31008
NUT
40
01643-71032
WASHER
41
20Y-53-11540
SEAL
42
20Y-54-51420
SEAL
43
20Y-53-12531
COVER
44
20Y-53-12310
COLLAR
45
01245-00616
SCREW
46
01643-70623
WASHER
