/ / / / / / КЛАПАН РУЛЕВОГО УПРАВЛЕНИЯ (ВНУТР. ЧАСТИ)
Запчасти Komatsu PW150ES-6K КЛАПАН РУЛЕВОГО УПРАВЛЕНИЯ (ВНУТР. ЧАСТИ) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ
1
1
1
2
3
4
5
6
7
8
9
10
11
12
13
13
14
14
14
14
14
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
1
20G-60-K2271
VALVE ASS'Y,STEERING
2
20G-60-K3330
RING,SEAL (KIT)
3
20G-60-K3340
BOLL
4
20G-60-K3350
BUSHING
5
20G-60-K3360
O-RING (KIT)
6
20G-60-K3370
BEARING
7
20G-60-K3380
RING
8
20G-60-K3390
PIN
9
20G-60-K3410
SPRING SET
10
20G-60-K3420
SHAFT
11
20G-60-K3430
O-RING (KIT)
12
20G-60-K3440
PLATE
13
20G-60-K3450
GEAR
14
20G-60-K3460
O-RING (KIT)
15
20G-60-K3470
COVER,END
16
20G-60-K3480
WASHER (KIT)
17
20G-60-K3490
SCREW
18
20G-60-K3510
PLATE,NAME
19
20G-60-K3520
VALVE ASS'Y,RELIEF
20
20G-60-K3530
SPRING
21
20G-60-K3540
VALVE ASS'Y
22
20G-60-K3550
BOLL
23
20G-60-K3560
BUSHING
24
20G-60-K3570
VALVE
25
20G-60-K3580
BOLL
26
20G-60-K3590
PIN
27
20G-60-K3610
SHAFT
28
20G-60-K3620
PLATE
29
20G-60-K3630
PLATE
30
20G-60-K3640
HOUSING
31
20G-60-K3650
SPRING
32
20G-60-K3660
PIN
33
20G-60-K3670
VALVE
KIT
20G-60-K3680
REPAIR PARTS
