ЗАДН. МОСТ (/) (.M ШИР.)

Запчасти Komatsu PW160-7K ЗАДН. МОСТ (/) (.M ШИР.) SUSPENTION И КОЛЕСА

Схема запчастей Komatsu PW160-7K - ЗАДН. МОСТ (/) (.M ШИР.) SUSPENTION И КОЛЕСА
16
17
18
13
19
23
1
21
19
22
15
8
12
11
20
10
9
3
2
7
5
6
4
14
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$1

20G-22-31001

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.S1150-61A0 TO S1150-64A0.

1

20G-23-31390

HUB

2

20G-22-31130

GEAR

3

20G-22-31140

SLEEVE

|4

20G-23-32110

PLANETARY ASS'Y

4

20G-23-31360

HOLDER,PLANETARY

5

20K-22-31170

GEAR,SPUR

6

20K-22-31190

BEARING,ROLLER

7

20G-23-31370

CIRCLIP

8

20G-22-31150

SHAFT

9

20K-22-31230

WHEEL

10

20K-22-31240

CIRCLIP

11

20K-22-31250

WASHER

12

20K-22-31260

BUSHING

13

20K-22-31270

PLUG

14

20K-22-31280

PLUG

15

20K-22-31310

GASKET

16

20G-23-31670

VALVE,AIR

17

20G-23-31510

FITTING,TUBE

18

20K-22-31360

PLUG

19

20G-23-31450

BEARING,ROLLER

20

20K-22-31380

SCREW

21

20K-22-31390

SCREW

22

20G-22-31180

CIRCLIP

23

20G-22-31190

O-RING
