Запчасти Komatsu PW160-8 ЗАДН. ОТВАЛ ЗАДН. ОТВАЛ
31
30
29
33
32
6
1
6
9
8
6
24
22
21
6
22
20
21
22
25
7
9
8
25
22
21
2
22
7
24
22
21
23
2
10
11
5
3
4
4
3
5
26
10
14
12
10
11
15
13
27
28
16
18
16
25
18
17
19
18
19
17
18
24
a
a
b
b
1
20G-910-3205
Blade Assembly
2
20G-61-31121
Cylinder Assembly
3
02783-10315
Elbow
4
07002-12034
O-Ring
5
02896-61009
O-Ring
6
20G-910-3282
Pin
7
20G-910-3290
Pin
8
01010-81016
Bolt
9
144-854-1890
Washer
10
20G-910-3282
Pin
11
20G-910-3290
Pin
12
01010-81016
Bolt
13
01010-81016
Bolt
14
144-854-1890
Washer
15
144-854-1890
Washer
|$16
20G-910-3442
Top Link Assembly
16
20G-910-3452
Link
17
20K-910-3470
Bushing
18
07145-00050
Seal
19
07020-00000
Fitting, Grease
|$21
20G-910-3562
Lower Link Assembly
20
20G-910-3332
Link
21
20K-910-3470
Bushing
22
07145-00050
Seal
23
07020-00000
Fitting, Grease
24
20G-910-3110
Spacer
25
20G-910-3120
Spacer
26
20G-910-3484
Bracket Assembly
27
01010-82060
Bolt
28
01643-32060
Washer
29
20K-910-3321
Bracket
30
20G-47-K1690
Reflector
31
01220-40516
Screw
32
01434-10820
Bolt, Wing
33
01643-30823
Washer
