Запчасти Komatsu PW170ES-6K ОБОГРЕВАТЕЛЬ. K КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ
1
2
2
2A
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
18A
18B
19
19
20
20
21
21
22
22
23
24
25
26
27
28
29
30
31
32
32
33
34
35
36
36
36
36
37
38
39
39
40
1
20Y-977-K392
HEATER ASSEMBLY
|1
20Y-977-K391
HEATER ASSEMBLY
2
01010-81025
BOLT
2A
20Y-970-K760
SPACER
3
01643-31032
WASHER
4
20Y-977-K230
SEAL
5
20Y-977-K240
FILTER ASSEMBLY
6
20Y-977-K260
ELEMENT
7
20Y-977-K280
NUT
8
01580-10605
NUT
9
01643-30623
WASHER
10
20Y-977-K380
DUCT
11
20Y-977-K310
CABLE
12
20Y-977-K321
CABLE
13
20Y-977-K340
CONTROLLER ASSEMBLY
|13
20Y-977-K360
KNOB
14
20Y-977-K370
SWITCH
15
01023-10510
SCREW
16
20E-06-K1870
RESISTOR
17
08036-10610
CLIP
18
206-979-K320
CLIP
18A
20Y-977-K460
CLIP
18B
20Y-977-K480
CLIP
19
09483-00527
HOSE
20
203-62-58210
MARK, T1
21
09483-00522
HOSE
22
203-62-58220
MARK, T2
23
08036-02514
CLIP
24
01010-81225
BOLT
|24
01010-51225
BOLT
25
01643-31232
WASHER
26
421-07-11550
CLIP
27
01010-81225
BOLT
|27
01010-51225
BOLT
28
01643-31232
WASHER
29
421-07-11550
CLIP
30
01010-81225
BOLT
|30
01010-51225
BOLT
31
01643-31232
WASHER
32
08036-02514
CLIP
33
01010-81025
BOLT
|33
01010-51025
BOLT
34
01643-31032
WASHER
35
08034-00536
BAND
36
07281-00259
CLAMP
37
20Y-977-K490
ELBOW
38
203-62-41150
COVER
39
08034-00823
BAND
40
08034-00536
BAND
