МОТОР ХОДА (ПЕРЕДН.) (ВНУТР. ЧАСТИ) (/)

Запчасти Komatsu PW170ES-6K МОТОР ХОДА (ПЕРЕДН.) (ВНУТР. ЧАСТИ) (/) F СИЛОВАЯ ПЕРЕДАЧА

Схема запчастей Komatsu PW170ES-6K - МОТОР ХОДА (ПЕРЕДН.) (ВНУТР. ЧАСТИ) (/) F СИЛОВАЯ ПЕРЕДАЧА
31
29
35
30
38
22
28
17
18
20
19
21
32
36
26
24
25
37
5
4
8
3
2
1
33
23
27
34
7
6
11
13
12
14
16
9
15
10
15
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|1

20G-60-K3280

MOTOR ASSEMBLY,TRAVEL, FRONT (20KPH)

|1

20G-60-K3880

MOTOR ASSEMBLY,TRAVEL, FRONT (30KPH)

|1

20G-60-K3090

MOTOR ASSEMBLY

|1

20G-60-K3920

CONTROL

|1

20G-60-K4110

CONTROL

1

20G-60-K2630

HOUSING

2

20G-60-K2640

BUSHING

3

20G-60-K2650

PISTON

4

20G-60-K2660

BUSHING

5

20G-60-K2670

BOLT

6

20G-60-K4290

SPRING

7

20G-60-K2690

SPRING

8

20G-60-K4310

O-RING (K1)

9

20G-60-K2710

SCREW

10

20G-60-K4320

SCREW (K1)

11

20G-60-K2730

RING

12

20G-60-K1490

STUD

13

20G-60-K2740

PIN

14

20G-60-K1520

NUT

15

20G-60-K2750

PIN

16

20G-60-K2760

DISC

|17

20G-60-K4120

COVER ASSEMBLY

17

20G-60-K4330

COVER

18

20G-60-K4340

SCREW

19

20G-60-K4350

SCREW

20

20G-60-K4360

O-RING (K1)

21

20G-60-K4320

SCREW (K1)

22

20E-60-K2670

VALVE ASSEMBLY

23

20G-60-K4140

PLATE

24

20G-60-K4150

PISTON

25

20G-60-K4160

TRUNNION

26

20G-60-K4170

RETAINER

27

20G-60-K4180

PIN

28

20G-60-K6050

PLUG ASSEMBLY

|28

O-RING

|28

O-RING

29

20G-60-K2560

SCREW

30

20G-60-K4210

SCREW

31

20G-60-K4230

O-RING (K1)

32

20G-60-K4250

SCREW

33

20G-60-K4260

RING (K1)

34

20G-60-K2580

PIN

35

20G-60-K4270

PIN

36

20G-60-K2590

PIN

37

20G-60-K4280

O-RING (K1)

38

20G-60-K3950

SCREW (K1)

K1

20G-60-K4390

SEAL KIT,MOTOR

K2

20G-60-K4410

SEAL KIT,DRIVE SHAFT
