/ / / / / / / КАБИНА, ПОЛ, PPC ТРУБЫ И КРЕПЛЕНИЕ
Запчасти Komatsu PW180-10 КАБИНА, ПОЛ, PPC ТРУБЫ И КРЕПЛЕНИЕ КАБИНА
a
22
a
b
23
b
c
c
d
d
24
16
3
24
2
1
6
5
4
5
3
16
5
7
8
8
9
21
25
7
9
5
17
26
2
26
1
6
5
4
5
12
13
14
14
13
15
10
11
18
15
14
15
14
15
12
11
13
19
14
10
13
14
20
27
32
27
31
32
29
31
28
30
32
32
31
32
29
31
31
|$1
20G-62-41150
Hose Assembly, RHS
1
20Y-62-42251
Hose
2
20G-62-41260
Hose
3
02760-00216
Hose
4
20Y-62-22820
Band, Blue
5
20Y-62-22830
Band, White
6
20Y-62-22790
Band, Red
7
20Y-62-22860
Band, Brown
8
20Y-62-22840
Band, Black
9
20Y-62-22850
Band, Green
|$11
20G-62-41141
Hose Assembly, LHS
10
20G-62-41180
Hose
11
208-62-72870
Hose
12
02764-00219
Hose
13
20Y-62-22790
Band, Red
14
20Y-62-22810
Band, Yellow
15
20Y-62-22820
Band, Blue
16
20G-62-41890
Hose
16
20Y-62-22810
Band, Yellow
16
20Y-62-22790
Band, Red
17
20G-62-41880
Hose
17
20Y-62-22820
Band, Blue
17
20Y-62-22810
Band, Yellow
18
08034-20536
Band
19
20Y-53-14140
Grommet
20
08034-20536
Band
21
04434-53411
Clip
22
01010-81020
Bolt
23
01643-31032
Washer
24
08034-20536
Band
25
20Y-54-65121
Grommet
26
08034-20536
Band
27
20Y-62-27770
Clamp
28
20G-54-41160
Clamp
29
04435-51310
Clip
30
20Y-62-15951
Clip
31
01010-81016
Bolt
32
01643-31032
Washer
