/ / / / / / / СМАЗКА ONE-ЧАСТИ СТРЕЛА, С АВТОМАТИЧ. СМАЗКОЙ, СТРЕЛА
Запчасти Komatsu PW180-10 СМАЗКА ONE-ЧАСТИ СТРЕЛА, С АВТОМАТИЧ. СМАЗКОЙ, СТРЕЛА СМАЗКА ONE-ЧАСТИ СТРЕЛА, С АВТОМАТИЧ. СМАЗКОЙ, СТРЕЛА
a
a
14
12
15
12
15
14
15
3
2
1
2
3
15
43
7
6
10
9
21
16
4
17
21
15
18
8
20
33
5
27
45
19
45
44
44
43
31
32
30
27
43
22
24
44
23
27
28
45
35
26
42
41
29
36
37
32
31
32
31
24
16
38
23
17
39
31
32
40
34
25
26
26
33
15
26
12
13
8
9
37
11
8
12
9
15
13
11
12
13
A
B
C
D
E
F
A
B
C
D
E
F
1
20J-S95-5290
Feeder, Boom
2
42W-09-H4650
Valve
3
42W-09-H2940
Cap
4
42W-09-H6790
Straight Connector
5
42W-09-H3330
Elbow
6
421-09-H3870
Nipple
7
42W-09-H3350
Cap
8
42W-09-H0P00
Hose, 5m
8
42W-09-H0P01
Hose, 10m
8
42W-09-H0P02
Hose, 15m
9
423-00-H1920
Bushing
10
42T-09-H4090
Tube, 45 Degrees
11
421-00-H0P13
Tube
12
42W-09-H2940
Cap
13
419-09-H2970
Elbow
14
419-09-H2950
Connector
15
42W-09-H0P06
Hose, 5m
15
42W-09-H0P07
Hose, 10m
15
42W-09-H0P08
Hose, 15m
16
01010-80645
Bolt
17
01643-30623
Washer
18
42W-09-H3340
Block
19
01010-80630
Bolt
20
01643-30623
Washer
21
42W-09-H2880
Union
22
20J-S95-5990
Bracket
23
01010-81025
Bolt
24
01643-31032
Washer
25
20J-S95-5620
Plate
26
04435-51810
Clip
27
04435-51510
Clip
28
01572-21012
Seat
29
04435-50810
Clip
30
04435-51812
Clip
31
01010-81016
Bolt
32
01643-31032
Washer
33
421-00-H0260
Band
34
20J-S95-5970
Feeder, Boom
35
42W-09-H2880
Union
36
42W-09-H5720
Switch, Cycle
37
20K-09-41110
Cable, Cycle Switch
38
07005-01412
Seal Washer
39
20K-09-41130
Straight Connector
40
42W-09-H3330
Elbow
41
421-09-H3870
Nipple
42
42W-09-H3350
Cap
43
42W-09-H0P03
Hose, 5m
43
42W-09-H0P04
Hose, 10m
43
42W-09-H0P05
Hose, 15m
44
419-S95-HP14
Bushing
45
419-S95-HP13
Tube
