Запчасти Komatsu PW75-1 ГИДРОЛИНИЯ ЗАДН. ОТВАЛ УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ
a
39
a
a
b
b
b
c
c
d
d
38
19
39
20
37
21
26
21
27
20
35
26
25
27
36
21
19
25
22
23
21
34
24
33
32
30
41
31
30
31
29
29
28
32
40
39
14
19
13
16
7
15
8
20
1
11
4
3
12
9
10
6
18
5
2
14
17
16
15
1
21D-60-17200
VALVE, ASSY.
2
21D-60-17250
KIT, GASKET
3
21D-62-15310
UNION
4
21D-09-69910
O-RING
5
21D-62-15290
UNION
6
21D-09-69910
O-RING
7
21D-09-51660
ELBOW
8
21D-09-69910
O-RING
9
21D-09-51220
UNION
10
21D-09-69910
O-RING
11
21D-09-55630
ELBOW
12
21D-09-55650
ELBOW
13
21D-62-11790
FLANGE
14
21D-09-69110
O-RING
15
01252-40830
SCREW
16
21D-09-73690
SPRING WASHER
17
21D-09-53120
FLANGE
18
21D-62-13640
PIPE
19
21D-09-95410
HOSE
20
21D-09-95420
HOSE
21
21D-09-57280
ELBOW
22
22E-62-11970
PIPE
23
22E-62-11980
PIPE
24
21D-09-57450
UNION
25
21D-09-68180
HOSE-CLAMP
26
01010-50630
BOLT
27
01643-30623
WASHER
28
22E-62-11960
PIPE
29
21D-09-68220
CLAMP
30
01016-50830
BOLT
31
01643-30823
WASHER
32
21D-09-93490
HOSE
33
21D-09-51230
UNION
34
21D-09-69970
O-RING
35
21D-09-51220
UNION
36
21D-09-69910
O-RING
37
21D-09-55630
ELBOW
38
21D-09-52530
UNION
39
22E-09-12610
HOSE
40
22E-62-11940
PIPE
41
22E-62-11950
PIPE
