Запчасти Komatsu PW95R-2 БОКОВ. КРЫШКА ДВИГ. ЧАСТИ КОРПУСА И КАБИНА
32
a
12
b
15
b
3
a
17
2
7
11
1
10
6
9
12
36
8
30
9
4
2
8
3
5
3
31
16
14
9
14
9
13
29
19
18
21
20
35
28
27
22
24
23
8
33
26
9
34
9
25
A
1
21D-54-11112
HOOD
2
01010-51025
BOLT
3
01643-31032
WASHER
4
21D-54-11590
GASKET
5
22E-54-11330
GASKET
6
21D-54-11970
GASKET
7
21D-54-11121
COVER
8
01010-50820
BOLT
9
01643-30823
SPRING WASHER
10
21D-54-11880
GASKET
11
21D-54-11870
GASKET
12
226-54-11450
HINGE
13
21D-54-11192
DAMPER
14
21D-09-85140
PIN, COTTER
15
226-54-11312
HOOD
16
226-54-11440
GASKET
17
20M-54-72250
BOOT
18
22E-54-11650
PUSH-BUTTON, ASSY.
19
226-54-11140
SPACER
20
21D-09-14120
SCREW
21
01580-10605
NUT
22
226-54-11130
LOCK, ASSY.
23
21D-09-15150
SCREW
24
01580-10806
NUT
25
22E-54-11360
SUPPORT
26
21D-54-11260
PIN
27
01643-31232
WASHER
28
22E-54-11270
NUT
29
226-54-11170
HANDLE
30
21D-54-11890
GASKET
31
01010-51030
BOLT
32
21D-54-11660
SHIM
33
21D-09-81700
COLLAR
34
01010-51016
BOLT
35
01643-31032
WASHER
36
22E-54-11640
SHIM
