Запчасти Komatsu PW98MR-6 ЗАДН. МОСТ (7/8) НИЖН.CARRIAGE
12
2
11
9
43
3
8
4
16
1
13
15
19
3
14
5
18
17
3
44
10
22
6
24
23
25
7
26
27
28
20
29
30
24
21
33
31
33
33
32
31
32
35
32
34
40
32
36
37
38
39
41
40
42
\0
21W-22-R1010
REAR AXLE, ASSEMBLY
1
226-22-12170
BRAKE CYLINDER
2
21D-22-11310
KIT, GASKET
3
226-22-12180
NUT
4
226-22-12190
ROD
5
22E-22-12320
SUPPORT
6
22E-22-12350
SPACER
7
22E-22-12340
RING, SNAP
8
226-22-12160
LEVER
9
22E-22-12360
GREASE NIPPLE
10
226-22-12010
LEVER
11
22E-22-11980
WASHER
12
22E-22-11990
SCREW
13
226-22-11981
BUSHING
14
226-22-11970
SCREW
15
226-22-11990
DOWEL
16
22E-22-12230
NUT
17
22E-22-12410
O-RING
18
21D-23-12490
VALVE
19
22E-23-11990
PLUG
20
226-22-11960
LEVER
21
DG014020913
PIN
22
226-22-12110
SPRING
23
DG1120770304
PISTON
24
21D-22-11290
PIN
25
226-22-12120
RING, WEAR
26
226-22-12130
O-RING
27
226-22-12070
O-RING
28
226-22-12060
RING, WEAR
29
226-22-12150
PISTON
30
226-22-12041
SELF ADJUST
31
DG1120703710
SCREW
32
226-22-12020
BRAKE DISK
33
226-22-12140
BRAKE DISK
33
DG1120761004
BRAKE DISK
34
DG1120770303
PISTON
35
226-22-12041
SELF ADJUST
36
226-22-12060
RING, WEAR
37
226-22-12070
O-RING
38
226-22-12130
O-RING
39
226-22-12120
RING, WEAR
40
226-22-12050
PISTON
41
21D-22-11290
PIN
42
226-22-12090
LEVER
43
22E-22-11960
O-RING
44
226-22-12250
O-RING
