|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$4
714-23-10023
TRANSMISSION ASS'Y
SN: 11265-UP
1шт.
|$6
714-23-10021
TRANSMISSION ASS'Y
SN: 10001-11264
1шт.
|$7
0
TRANSMISSION ASS'Y
SN: (10001-11057)
1шт.
|$$5
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F5350-51A0 TO F5350-70A0.
-1шт.
|$12
714-23-12012
CLUTCH ASS'Y,FORWARD LOW AND REVERSE
SN: 10001-UP
1шт.
|$13
714-23-12112
SHAFT AND CYLINDER A,FORWARD LOW AND REVERSE
SN: 10001-UP
1шт.
1
0
SHAFT,INPUT
SN: 10001-UP
1шт.
2
0
HOUSING
SN: 10001-UP
1шт.
3
714-11-19390
BALL,FORWARD LOW AND REVERSE
SN: 10001-UP
2шт.
4
07043-70211
PLUG
SN: 10001-UP
1шт.
5
419-15-12140
RING,SNAP
SN: 10001-UP
2шт.
6
714-23-12640
PISTON,FORWARD LOW AND REVERSE
SN: 10001-UP
2шт.
7
04020-00514
PIN
SN: 10001-UP
4шт.
8
362-15-19520
RING
SN: 10001-UP
2шт.
9
714-23-12680
PISTON,FORWARD LOW AND REVERSE
SN: 10001-UP
2шт.
10
714-12-19711
DISC
SN: 10001-UP
16шт.
11
714-16-19730
PLATE,SEPARATE
SN: 10001-UP
18шт.
12
56D-15-12710
SPRING,WAVE
SN: (100201)-UP
16шт.
12
0
SPRING,WAVE
SN: 10001-(100200)
16шт.
13
714-12-12610
PLATE,END
SN: 10001-UP
2шт.
14
714-11-19230
RING,SEAL
SN: 10001-UP
2шт.
15
714-07-19320
RING,SEAL (K1)
SN: 10001-UP
2шт.
16
714-08-19560
WASHER
SN: 10001-UP
2шт.
17
419-15-12640
BEARING
SN: 10001-UP
2шт.
18
419-15-12650
WASHER
SN: 10001-UP
2шт.
19
714-12-12760
WASHER
SN: 10001-UP
2шт.
20
714-23-19420
BEARING,NEEDLE
SN: 10001-UP
1шт.
21
714-23-19410
BEARING,NEEDLE
SN: 10001-UP
1шт.
22
714-12-12740
SPACER
SN: 10001-UP
1шт.
23
714-23-19320
BEARING
SN: 10001-UP
1шт.
24
714-23-19310
BEARING
SN: 10001-UP
1шт.
25
714-23-12411
GEAR,FORWARD LOW
SN: 10001-UP
1шт.
26
714-23-12531
GEAR,INPUT, FORWARD HI
SN: 10001-UP
1шт.
27
04066-00062
RING,SNAP
SN: 10001-UP
1шт.
28
714-23-12420
GEAR,REVERSE
SN: 10001-UP
1шт.
29
714-07-12290
RING,SEAL
SN: 10001-UP
2шт.
30
419-15-12122
RING
SN: 10001-UP
3шт.
31
714-21-19810
RING,SEAL
SN: 10001-UP
2шт.
