Запчасти Komatsu GD650A ROADSTER КАБИНА ОПЕРАТОРА SUPERSTRUCTURE

|$0

1433 858 H91

ROADSTER ASSEMBLY

1шт.

1

1433 933 H91

ROADSTER WELDMENT

1шт.

2

1433 778 H1

COVER

1шт.

3

160 541

SCREW, MACHINE

3шт.

|$4

120 392

WASHER, FLAT

3шт.

4

149 149

SEAL, WEATHER - 11.91 IN

1шт.

|$6

104 696

ADHESIVE, RUBBER

-2шт.

5

PLATE, FLOOR (SEE PG 12-030)

-29шт.

6

180 124

BOLT

8шт.

|$9

28 422 R1

WASHER, FLAT

8шт.

7

BOX ASSEMBLY, SEAT (SEE PG 13-050)

-29шт.

|$11

20 537 R1

BOLT - SEAT BOX TO FLOOR PLATE

7шт.

|$12

28 422 R1

WASHER, FLAT

7шт.
