Запчасти Komatsu GD650A ТУРБОНАГНЕТАТЕЛЬ ТРУБЫ ГОЛОВКА ЦИЛИНДРОВ

1

6732-71-3220

BOLT (M8x1.25x20)

2шт.

2

1294 088 H1

GASKET, TURBOCHARGER

1шт.

3

1296 874 H1

HOSE, FLEXIBLE

1шт.

|$3

6736-51-8140

CONNECTOR, FEMALE

2шт.

4

6736-51-8710

O-RING

1шт.

5

NSS

CONNECTOR, FEMALE

1шт.

6

6736-51-8730

WASHER, SEALING

2шт.

7

6732-51-8330

SEAL, O-RING

2шт.

8

1304 836 H1

CONNECTION, TURBINE OIL DRAIN

1шт.

|$13

-1шт.

|$10

F1 - IGNORE THESE ITEMS FOR SERVICE PURPOSES.

-1шт.

|$11

THE O-RINGS AND CONNECTORS ARE INSTALLED AT CUMMINS AND ARE REMOVED

-1шт.

|$12

AT GALION TO INSTALL THE TURBO LUBE KIT.

-1шт.
