|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$3
714-23-10021
TRANSMISSION ASS'Y
SN: 11028-UP
1шт.
|$4
714-23-10020
TRANSMISSION ASS'Y
SN: 10001-11027
1шт.
|$$4
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F5350-51A0 TO F5350-70A0.
-1шт.
|$7
714-23-12022
CLUTCH ASS'Y,FORWARD HI AND 1ST
SN: 10001-UP
1шт.
|$8
714-23-12122
SHAFT AND CYLINDER A,FORWARD HI AND 1ST
SN: 10001-UP
1шт.
1
0
SHAFT,UPPER
SN: 10001-UP
1шт.
2
714-11-19390
BALL
SN: 10001-UP
2шт.
3
0
HOUSING,FORWARD HI AND 1ST
SN: 10001-UP
2шт.
4
714-23-12651
PISTON,FORWARD AND REVERSE
SN: 10001-UP
1шт.
5
714-23-12671
PISTON,FORWARD HI AND REVERSE
SN: 10001-UP
1шт.
6
04020-00514
PIN
SN: 10001-UP
2шт.
7
362-15-19520
RING
SN: 10001-UP
1шт.
8
714-23-12690
PISTON,RANGE
SN: 10001-UP
1шт.
9
419-15-12140
RING,SNAP
SN: 10001-UP
2шт.
10
714-12-19711
DISC
SN: 10001-UP
17шт.
11
714-16-19730
PLATE,SEPARATE
SN: 10001-UP
19шт.
12
56D-15-12710
SPRING,WAVE
SN: (100197)-UP
17шт.
12
0
SPRING,WAVE
SN: 10001-(100196)
17шт.
13
714-12-12610
PLATE,END
SN: 10001-UP
2шт.
14
714-08-19220
RING,SEAL (K1)
SN: 10001-UP
1шт.
15
714-16-19220
RING,SEAL
SN: 10001-UP
1шт.
16
714-07-19320
RING,SEAL (K1)
SN: 10001-UP
2шт.
17
714-08-19560
WASHER
SN: 10001-UP
2шт.
18
714-08-19570
WASHER,THRUST
SN: 10001-UP
1шт.
19
419-15-12640
BEARING
SN: 10001-UP
1шт.
20
419-15-12650
WASHER
SN: 10001-UP
1шт.
21
714-12-12760
WASHER
SN: 10001-UP
1шт.
22
714-23-19631
BUSHING,1ST
SN: 10001-UP
1шт.
23
714-23-19410
BEARING,NEEDLE
SN: 10001-UP
1шт.
24
714-12-12740
SPACER
SN: 10001-UP
1шт.
25
714-23-19320
BEARING
SN: 10001-UP
1шт.
26
714-23-12431
GEAR,FOWARD HI
SN: 10001-UP
1шт.
27
714-23-12441
GEAR,1ST
SN: 10001-UP
1шт.
28
04066-00062
RING,SNAP
SN: 10001-UP
1шт.
29
419-15-12122
RING
SN: 10001-UP
3шт.
30
714-23-12561
GEAR,UPPER
SN: 10001-UP
1шт.
31
714-23-19330
BEARING
SN: 10001-UP
1шт.
