|1
714-23-10024
TRANSMISSION ASS'Y
SN: B15076-UP
1шт.
|1
714-23-10021
TRANSMISSION ASS'Y
SN: B15001-B15075
1шт.
|$1
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F5350-51A0 TO F5350-70A0.
-1шт.
|1
714-23-12023
CLUTCH ASS'Y {FORWARD HI AND 1ST}
SN: B15076-UP
1шт.
|1
714-23-12022
CLUTCH ASS'Y {FORWARD HI AND 1ST}
SN: B15001-B15075
1шт.
|1
714-23-12123
SHAFT AND CYLINDER A {FORWARD HI AND 1ST}
SN: B15076-UP
1шт.
|1
714-23-12122
SHAFT AND CYLINDER A {FORWARD HI AND 1ST}
SN: B15001-B15075
1шт.
1
0
SHAFT {UPPER}
SN: B15001-UP
1шт.
2
714-11-19390
BALL
SN: B15001-UP
2шт.
3
0
HOUSING {FORWARD HI AND 1ST}
SN: B15001-UP
2шт.
4
714-23-12650
PISTON {FORWARD AND REVERSE}
SN: B15001-UP
1шт.
5
23B-45-72670
PISTON {FORWARD HI AND REVERSE}
SN: B15076-UP
1шт.
|5
714-23-12670
PISTON {FORWARD HI AND REVERSE}
SN: B15001-B15075
1шт.
6
04020-00514
PIN
SN: B15001-UP
2шт.
7
362-15-19520
RING
SN: B15001-UP
1шт.
8
714-23-12690
PISTON {RANGE}
SN: B15001-UP
1шт.
9
419-15-12140
RING {SNAP}
SN: B15001-UP
2шт.
10
714-12-19711
DISC
SN: B15001-UP
17шт.
11
714-16-19730
PLATE {SEPARATE}
SN: B15001-UP
19шт.
12
419-15-12133
SPRING {WAVE}
SN: B15001-UP
17шт.
13
714-12-12610
PLATE {END}
SN: B15001-UP
2шт.
14
714-08-19220
RING {SEAL} (K1)
SN: B15001-UP
1шт.
15
714-16-19220
RING {SEAL}
SN: B15001-UP
1шт.
16
714-07-19320
RING {SEAL} (K1)
SN: B15001-UP
2шт.
17
714-08-19560
WASHER
SN: B15001-UP
2шт.
18
714-08-19570
WASHER {THRUST}
SN: B15001-UP
1шт.
19
419-15-12640
BEARING
SN: B15001-UP
1шт.
20
419-15-12650
WASHER
SN: B15001-UP
1шт.
21
714-12-12760
WASHER
SN: B15001-UP
1шт.
22
714-23-19631
BUSHING {1ST}
SN: B15001-UP
1шт.
23
714-23-19410
BEARING {NEEDLE}
SN: B15001-UP
1шт.
24
714-12-12740
SPACER
SN: B15001-UP
1шт.
25
714-23-19320
BEARING
SN: B15001-UP
1шт.
26
714-23-12431
GEAR {FOWARD HI}
SN: B15001-UP
1шт.
27
714-23-12441
GEAR {1ST}
SN: B15001-UP
1шт.
28
04066-00062
RING {SNAP}
SN: B15001-UP
1шт.
29
714-23-19330
BEARING
SN: B15001-UP
1шт.
30
714-23-12561
GEAR {UPPER}
SN: B15001-UP
1шт.
31
419-15-12122
RING
SN: B15001-UP
3шт.
