|1
707-00-0J430
Cylinder Assembly,LHS
SN: B40001-UP
1шт.
1
721-11-50660
Cylinder
SN: B40001-UP
1шт.
2
02896-11009
O-ring, (Kit : K05)
SN: B40001-UP
1шт.
3
707-61-35760
Rod, Piston
SN: B40001-UP
1шт.
4
07020-00900
Fitting, Grease
SN: B40001-UP
1шт.
5
707-76-35010
Bushing
SN: B40001-UP
1шт.
6
04065-05520
Ring, Snap, for Hole Side
SN: B40001-UP
2шт.
7
707-29-50981
Head, Cylinder
SN: B40001-UP
1шт.
8
707-56-35740
Seal, Dust, (Kit : K05)
SN: B40001-UP
1шт.
9
07179-00054
Ring, Snap
SN: B40001-UP
1шт.
10
707-51-35210
Packing, Rod, (Kit : K05)
SN: B40001-UP
1шт.
11
707-52-15110
Bushing
SN: B40001-UP
1шт.
12
07000-13048
O-ring, (Kit : K05)
SN: B40001-UP
1шт.
13
07000-13045
O-ring, (Kit : K05)
SN: B40001-UP
1шт.
14
707-35-99500
Ring, Back-up, (Kit : K05)
SN: B40001-UP
1шт.
15
707-36-50400
Piston
SN: B40001-UP
1шт.
16
707-44-50070
Ring, Piston, (Kit : K05)
SN: B40001-UP
1шт.
17
10E-63-32390
Ring, Wear, (Kit : K05)
SN: B40001-UP
1шт.
18
707-67-20020
Nut, Nylon
SN: B40001-UP
1шт.
19
07020-00000
Fitting, Grease
SN: B40001-UP
1шт.
20
07043-70108
Plug
SN: B40001-UP
1шт.
21
707-86-38100
Tube,LHS
SN: B40001-UP
1шт.
22
02782-10315
Elbow
SN: B40001-UP
1шт.
23
07002-12034
O-ring, (Kit : K05)
SN: B40001-UP
1шт.
24
02896-11009
O-ring, (Kit : K05)
SN: B40001-UP
2шт.
