1
234-60-33860
ELBOW
SN: 21001-UP
2шт.
2
07002-12034
O-RING
SN: 21001-UP
2шт.
3
07113-10410
HOSE,(FOR CHINESE)
SN: 21001-UP
2шт.
3
230-09-24100
HOSE,(FOR RUSSIAN)
SN: 21097-UP
2шт.
4
234-60-33910
TUBE
SN: 21001-UP
1шт.
5
234-60-33920
TUBE
SN: 21001-UP
1шт.
6
238-60-28190
NIPPLE
SN: 21001-UP
2шт.
7
07230-10422
UNION
SN: 21001-UP
1шт.
8
232-60-62960
NIPPLE
SN: 21001-UP
1шт.
9
07002-12034
O-RING
SN: 21001-UP
4шт.
10
232-61-11600
VALVE ASS'Y,PILOT CHECK
SN: 21001-UP
1шт.
11
234-60-33930
TUBE
SN: 21001-UP
1шт.
12
234-60-33940
TUBE
SN: 21001-UP
1шт.
13
07108-30417
HOSE,(FOR CHINESE)
SN: 21001-UP
2шт.
13
230-09-04170
HOSE,(FOR RUSSIAN)
SN: 21097-UP
2шт.
14
234-60-34480
TUBE
SN: 21001-UP
1шт.
15
234-60-34470
TUBE
SN: 21001-UP
1шт.
16
07108-30407
HOSE,(FOR CHINESE)
SN: 21001-UP
2шт.
16
230-09-04070
HOSE,(FOR RUSSIAN)
SN: 21097-UP
2шт.
17
234-60-34450
TUBE
SN: 21001-UP
1шт.
18
234-60-34460
TUBE
SN: 21001-UP
1шт.
19
07235-10422
ELBOW,(FOR CHINESE)
SN: 21001-UP
2шт.
19
07235-50422
ELBOW,(FOR RUSSIAN)
SN: 21097-UP
2шт.
20
07043-00108
PLUG
SN: 21001-UP
1шт.
21
07002-12034
O-RING
SN: 21001-UP
1шт.
22
234-60-33471
BAND
SN: 21001-UP
1шт.
23
234-60-33480
BAND
SN: 21001-UP
1шт.
24
01010-50830
BOLT
SN: 21001-UP
2шт.
25
01602-20825
WASHER,SPRING (FOR CHINESE)
SN: 21001-UP
2шт.
25
01643-30823
WASHER,(FOR RUSSIAN)
SN: 21097-UP
2шт.
26
232-60-54830
CLIP
SN: 21001-UP
2шт.
27
01010-51045
BOLT
SN: 21001-UP
1шт.
28
01602-21030
WASHER,SPRING (FOR CHINESE)
SN: 21001-UP
1шт.
28
01643-31032
WASHER,(FOR RUSSIAN)
SN: 21097-UP
1шт.
29
232-60-54820
CLIP
SN: 21001-UP
1шт.
30
01010-51020
BOLT
SN: 21001-UP
1шт.
31
01602-21030
WASHER,SPRING (FOR CHINESE)
SN: 21001-UP
1шт.
31
01643-31032
WASHER,(FOR RUSSIAN)
SN: 21097-UP
1шт.
