Запчасти Komatsu 450FXL-1 K7-A КОНДИЦ. ВОЗДУХА И ОБОГРЕВАТЕЛЬ. КРЕПЛЕНИЕ OPERATORXD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

1

10788KF

NUT, NYLOCK (5/16 IN)

SN: A10001--UP

6шт.

2

15559KF

WASHER, SAE FLAT (5/16 IN)

SN: A10001--UP

10шт.

3

27284KF

BRACKET, AIR CONDITIONER MOUNTING

SN: A10001--UP

2шт.

4

15606KF

WASHER, LOCK (5/16 IN)

SN: A10001--UP

4шт.

5

15589KF

BOLT (5/16 IN x 1 IN)

SN: A10001--UP

10шт.

6

24640KF

PANEL, AIR CONDITIONER HEADLINER

SN: A10001--UP

1шт.

7

10757KF

WASHER, SAE FLAT (1/4 IN)

SN: A10001--UP

2шт.

8

10756KF

WASHER, LOCK (1/4 IN)

SN: A10001--UP

2шт.

9

15604KF

BOLT (1/4 IN x 3/4 IN)

SN: A10001--UP

2шт.

10

AIR CONDITIONER AND HEATER ASSEMBLY ( SEE FIG. K0700-01A0 )

SN: A10001--UP

-1шт.
