Запчасти Komatsu XT445L-2 7-A МОТОР ХОДА (/) ВАЛ И RINGS ХОД СИСТЕМА И ITS КОМПОНЕНТЫ

|$29

MOTOR ASSEMBLY, FINAL DRIVE ( SEE FIG. P0700-01A0 )

0

-1шт.

1

706-8J-41910

SHAFT, DRIVE

1шт.

2

706-8J-41010

BEARING

1шт.

3

706-77-42890

BEARING

1шт.

4

706-8J-41810

RETAINER

1шт.

5

706-8J-41660

SPACER KIT

1шт.

|$6

NSS

SPACER, 2.1 MM

1шт.

|$7

NSS

SPACER, 2.3 MM

1шт.

|$8

NSS

SPACER, 2.5 MM

1шт.

|$9

NSS

SPACER, 2.7 MM

1шт.

|$10

NSS

SPACER, 1.9 MM

1шт.

6

04064-06525

RING

1шт.

7

706-8J-41620

SEAL

1шт.

8

706-8J-41820

SPACER

1шт.

9

04065-09030

RING

1шт.

10

706-8J-41270

RING

1шт.

11

706-8J-41590

SPRING

1шт.

12

706-8J-41550

RETAINER

1шт.

13

708-23-12350

SCREW

1шт.

|$19

706-8J-42260

PISTON SUBASSEMBLY

7шт.

14

706-8J-42270

PISTON

1шт.

15

706-8J-41380

RING, SEAL

1шт.

16

706-8J-41560

SHAFT, CENTER

1шт.

17

706-7K-91340

PLATE

6шт.

18

706-7K-91350

DISC

5шт.

19

706-8J-91140

PISTON, BRAKE

1шт.

20

708-8H-15220

O-RING

1шт.

21

07000-15230

O-RING

1шт.

22

706-8J-91130

SPRING

6шт.

|$30

29

-1шт.

|$31

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

30

-1шт.
