БЕЗОПАСН. КАБИНА, ДВЕРЬS

Запчасти Komatsu 77C БЕЗОПАСН. КАБИНА, ДВЕРЬS ШАССИ И SUPERSTRUCTURE

Схема запчастей Komatsu 77C - БЕЗОПАСН. КАБИНА, ДВЕРЬS ШАССИ И SUPERSTRUCTURE
9
7A
8A
1A
3A
34
7
8
7A
8A
33
32
5
6
31
35
7
36
8
32
35
9
36
1
21
3
22
10
11
16
23
30
29
2
17
4
18
26
19
2
20
27
4
24
25
37
16
27
15
28
12
26
13
14
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

4003549M91

DOOR

SN: 377520539

1шт.

1A

4004081M91

DOOR

SN: 377520540-377520571

1шт.

2

4202153M1

HINGE

EnglischBem: NOTE: Pos. (2) included in Pos. (1) and (1A) Kit

2шт.

3

4003550M91

DOOR

SN: 377520539

1шт.

3A

4004082M91

DOOR

SN: 377520540-377520571

1шт.

4

4202152M1

HINGE

EnglischBem: NOTE: Pos. (4) included in Pos. (3) and (3A) Kit

2шт.

5

4003507M91

SLIDING WINDOW

EnglischBem: LEFT FITTED WITH ALUMINIUM SECTIONAL NOTE: Pos. (5) included in

1шт.

|$42

SLIDING WINDOW

DeutschDesc: SCHIEBEFENSTER

-3шт.

6

4003506M91

SLIDING WINDOW

EnglischBem: RIGHT FITTED WITH ALUMINIUM SECTIONAL NOTE: Pos. (6) included in

1шт.

|$43

SLIDING WINDOW

DeutschDesc: SCHIEBEFENSTER

-3шт.

7

4201728M91

DOOR LOCK

SN: 377520538

1шт.

7A

4004947M91

DOOR LOCK

SN: 377520539-UP

1шт.

8

4201729M91

DOOR LOCK

SN: 377520538

1шт.

8A

4004946M91

DOOR LOCK

SN: 377520539-UP

1шт.

9

3005084X1

SCREW

EnglischBem: BELONGS ALSO TO THE SUPPLY UNIT OF DOOR 4004 081 M91 + 4004 082

4шт.

10

4201703M1

COVERING

EnglischBem: BELONGS ALSO TO THE SUPPLY UNIT OF DOOR 4004 081 M91 + 4004 082

2шт.

11

2995322X1

SCREW

EnglischBem: BELONGS ALSO TO THE SUPPLY UNIT OF DOOR 4004 081 M91 + 4004 082

2шт.

12

4201726M91

GRIP

EnglischBem: LEFT NOTE: Pos. (12) included in Pos. (1) and (1A) Kit

1шт.

13

4201727M91

GRIP

EnglischBem: RIGHT NOTE: Pos. (13) included in Pos. (3) and (3A) Kit

1шт.

14

4201724M1

UNDERLAY

EnglischBem: BELONGS ALSO TO THE SUPPLY UNIT OF DOOR 4004 081 M91 + 4004 082

2шт.

15

4202193M1

UNDERLAY

EnglischBem: BELONGS ALSO TO THE SUPPLY UNIT OF DOOR 4004 081 M91 + 4004 082

2шт.

16

3000387X1

SCREW

EnglischBem: BELONGS ALSO TO THE SUPPLY UNIT OF DOOR 4004 081 M91 + 4004 082

4шт.

17

4201723M91

LEVER

EnglischBem: LEFT NOTE: Pos. (17) included in Pos. (1) and (1A) Kit

1шт.

18

4201722M91

LEVER

EnglischBem: RIGHT NOTE: Pos. (18) included in Pos. (3) and (3A) Kit

1шт.

19

4202118M1

SPRING

EnglischBem: LEFT

1шт.

20

4202117M1

SPRING

EnglischBem: RIGHT

1шт.

21

4003567M1

ROD

EnglischBem: LEFT NOTE: Pos. (21) included in Pos. (1) and (1A) Kit

1шт.

22

4003566M1

ROD

EnglischBem: RIGHT NOTE: Pos. (22) included in Pos. (3) and (3A) Kit

1шт.

23

4202197M1

CLASP

EnglischBem: BELONGS ALSO TO THE SUPPLY UNIT OF DOOR 4004 081 M91 + 4004 082

2шт.

24

4003577M1

COVERING

EnglischBem: LEFT NOTE: Pos. (24) included in Pos. (1) and (1A) Kit

1шт.

25

4003576M1

COVERING

EnglischBem: RIGHT NOTE: Pos. (25) included in Pos. (3) and (3A) Kit

1шт.

26

3005093X1

SCREW

EnglischBem: BELONGS ALSO TO THE SUPPLY UNIT OF DOOR 4004 081 M91 + 4004 082

4шт.

27

390971X1

PLAIN WASHER

EnglischBem: BELONGS ALSO TO THE SUPPLY UNIT OF DOOR 4004 081 M91 + 4004 082

4шт.

28

2995335X1

SCREW

EnglischBem: BELONGS ALSO TO THE SUPPLY UNIT OF DOOR 4004 081 M91 + 4004 082

4шт.

29

3092811M1

PEG

DeutschDesc: STIFT

4шт.

30

339003X1

LUBRICATION NIPPLE

DeutschDesc: SCHMIERNIPPEL

4шт.

31

3085110M91

STRAP

DeutschDesc: LASCHE

2шт.

32

3084393M1

STRAP

DeutschDesc: LASCHE

4шт.

33

3001417X1

PIN

DeutschDesc: BOLZEN

4шт.

34

2993257X1

PIN

DeutschDesc: BOLZEN

2шт.

35

1442595X1

PLAIN WASHER

DeutschDesc: UNTERLEGSCHEIBE

6шт.

36

391405X1

COTTER

DeutschDesc: SPLINT

6шт.

37

4004500M1

GASKET

DeutschDesc: DICHTUNG

2шт.
