Запчасти Komatsu 77C SLIDING ОКНА ШАССИ И SUPERSTRUCTURE

1

4003506M91

SLIDING WINDOW

EnglischBem: RIGHT

1шт.

2

4003507M91

SLIDING WINDOW

EnglischBem: LEFT

1шт.

3

WINDOW FRAME

EnglischBem: ORDER 4003 506 M91

1шт.

4

WINDOW FRAME

EnglischBem: ORDER 4003 507 M91

1шт.

5

4907157M1

GLASS PANE

EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (2) Kit

2шт.

6

4907158M1

GLASS PANE

EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (2) Kit

2шт.

7

NOT USED

DeutschDesc: NICHT VERWENDET

-1шт.

8

4907159M91

GLASS PANE

EnglischBem: NOTE: Pos. (8) included in Pos. (1) and (2) Kit

2шт.

9

3252453M91

GRIP

EnglischBem: NOTE: Pos. (9) included in Pos. (1) and (2) Kit

4шт.

9A

4202721M91

GRIP

DeutschDesc: GRIFF

4шт.

9B

3232485M1

EXCLUDER

DeutschDesc: SPERRE

4шт.

10

4907168M1

SLAT

EnglischBem: RIGHT

1шт.

11

4907169M1

SLAT

EnglischBem: LEFT

1шт.

12

4907170M1

SLAT

EnglischBem: RIGHT

1шт.

13

4907171M1

SLAT

EnglischBem: LEFT

1шт.

14

4907174M91

SLAT

EnglischBem: NOTE: Pos. (14) included in Pos. (1) and (2) Kit

2шт.

15

4907175M91

SLAT

EnglischBem: NOTE: Pos. (15) included in Pos. (1) and (2) Kit

2шт.

16

PROFILE

EnglischBem: GOODS SOLD BY THE METER 3228 176 M1 NOTE: Pos. (16) included in

-26шт.

17

3252458M1

PROFILE

EnglischBem: GOODS SOLD BY THE METER 3252 464 M1 NOTE: Pos. (17) included in

2шт.

18

4907176M1

HOLDER

EnglischBem: NOTE: Pos. (18) included in Pos. (1) and (2) Kit

38шт.

19

4907177M1

SCREW

EnglischBem: NOTE: Pos. (19) included in Pos. (1) and (2) Kit

38шт.

20

COVERING

EnglischBem: GOODS SOLD BY THE METER 4907 178 M1 NOTE: Pos. (20) included in

-26шт.

21

RUBBER SECTIONAL

EnglischBem: GOODS SOLD BY THE METER 4907 179 M1 NOTE: Pos. (21) included in

-26шт.

22

RUBBER SECTIONAL

EnglischBem: GOODS SOLD BY THE METER 4907 180 M1 NOTE: Pos. (22) included in

-26шт.
