|$2
415-56-22444
CAB ASS'Y,(FOR SNOW BLADE)
SN: 12062-UP
1шт.
|$3
0
CAB ASS'Y,(FOR SNOW BLADE)
SN: 12023-12061
1шт.
|$4
415-56-22442
CAB ASS'Y,(FOR SNOW BLADE)
SN: 12001-12022
1шт.
|$5
415-56-22441
CAB ASS'Y,(FOR SNOW BLADE)
SN: 11546-12000
1шт.
|$6
415-56-22440
CAB ASS'Y,(FOR SNOW BLADE)
SN: 11501-11545
1шт.
|$7
415-56-22454
CAB ASS'Y,(FOR SNOW BLADE + RADIO)
SN: 12062-UP
1шт.
|$8
0
CAB ASS'Y,(FOR SNOW BLADE + RADIO)
SN: 12023-12061
1шт.
|$9
415-56-22452
CAB ASS'Y,(FOR SNOW BLADE + RADIO)
SN: 12001-12022
1шт.
|$10
415-56-22451
CAB ASS'Y,(FOR SNOW BLADE + RADIO)
SN: 11546-12000
1шт.
|$11
415-56-22450
CAB ASS'Y,(FOR SNOW BLADE + RADIO)
SN: 11501-11545
1шт.
|$$11
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01B5 TO K0210-18B6.
-1шт.
1
01220-40810
SCREW
SN: 11001-UP
4шт.
2
09415-01008
CAP,(WITHOUT BEACON LAMP)
SN: 11001-UP
1шт.
3
423-56-21960
STRIKER
SN: 11001-UP
2шт.
4
01240-00820
SCREW
SN: 11001-UP
4шт.
5
421-54-15760
WASHER
SN: 11001-UP
4шт.
6
419-54-15690
PLATE
SN: 11001-UP
4шт.
7
01010-80825
BOLT
SN: 11001-UP
12шт.
8
01643-30823
WASHER
SN: 11001-UP
12шт.
9
421-54-15730
SEAL,DOOR
SN: 11001-UP
2шт.
10
417-926-2261
BRACKET,L.H.
SN: 11001-UP
1шт.
11
417-926-2271
BRACKET,R.H.
SN: 11001-UP
1шт.
12
01435-01030
BOLT
SN: 11001-UP
4шт.
13
07005-01412
SEAL, WASHER
SN: 11001-UP
4шт.
14
42A-925-1530
CATCH
SN: 11001-UP
2шт.
15
417-926-2280
STOPPER
SN: 11001-UP
2шт.
16
01023-70430
SCREW
SN: 11001-UP
2шт.
17
416-64-15620
WASHER
SN: 11001-UP
2шт.
