1
CONTROL VALVE, 3-SPOOL (SEE PG 06-012)
-29шт.
2
417-64-13114
BRACKET, CONTROL VALVE MOUNTING - UPPER
1шт.
3
417-64-13123
BRACKET, CONTROL VALVE MOUNTING - LOWER
1шт.
4
01010-31025
BOLT, CONTROL VALVE MOUNTING
4шт.
5
01643-31032
WASHER
4шт.
6
419-43-17930
CUSHION, CONTROL VALVE MOUNTING BRACKET
4шт.
7
417-62-13620
CUSHION, CONTROL VALVE MOUNTING BRACKET
4шт.
8
417-62-14130
SPACER
4шт.
9
01010-31250
BOLT, CONTROL VALVE MOUNTING BRACKET
4шт.
10
419-43-17920
WASHER
4шт.
11
07230-20522
UNION
2шт.
12
07002-12434
O-RING
2шт.
13
416-877-1310
TUBE, CONTROL VALVE TO FRAME
1шт.
14
416-877-1320
TUBE, CONTROL VALVE TO FRAME
1шт.
15
07086-40514
HOSE, CONTROL VALVE TO FRAME
2шт.
16
416-877-1442
BRACKET, TUBE CLAMPING
1шт.
17
416-877-1480
SUPPORT, CLAMPING BRACKET
1шт.
18
01010-51230
BOLT, MOUNT BRACKET TO SUPPORT
1шт.
19
01643-31232
WASHER
1шт.
20
417-54-13470
SPACER
1шт.
21
417-62-13620
CUSHION
2шт.
22
419-43-17920
WASHER
2шт.
23
01010-51250
BOLT, MOUNT SUPPORT
1шт.
24
07283-32236
U-BOLT, CLAMP TUBES
2шт.
25
426-09-11160
NUT
4шт.
26
01643-31032
WASHER
4шт.
27
416-877-1361
STRIP, RUBBER - HOSE CLAMPING
1шт.
28
416-877-1410
SPACER
2шт.
29
01011-51240
BOLT, HOSE CLAMPING STRIP
2шт.
30
TUBES, AT FRAME TO BOOM (SEE PG 06-052)
-29шт.
