1
416-877-1340
TUBE, LH - FRAME TO CONTROL VALVE LINE
1шт.
2
416-877-1330
TUBE, RH - FRAME TO CONTROL VALVE LINE
1шт.
3
01010-51225
BOLT, TUBES TO FRAME
2шт.
4
01643-31232
WASHER
2шт.
5
07086-00509
HOSE, TUBES TO BOOM ARM
2шт.
6
416-877-1420
TUBE, LH - ON BOOM ARM
1шт.
7
416-877-1430
TUBE, RH - ON BOOM ARM
1шт.
8
07222-00414
PLUG (FOR SHIPPING)
2шт.
9
07221-20422
NUT, SLEEVE (FOR SHIPPING)
2шт.
10
416-877-1350
BRACKET, MOUNT TUBES TO INSIDE FRAME
1шт.
11
01010-31225
BOLT, BRACKET TO FRAME
2шт.
12
01643-31232
WASHER
2шт.
13
416-877-1450
BRACKET, TUBES TO FRAME
2шт.
14
01010-51235
BOLT, BRACKET TO FRAME
2шт.
15
01580-11210
NUT
2шт.
16
01643-31232
WASHER
2шт.
17
07283-32236
U-BOLT, TUBES TO BRACKETS
4шт.
18
426-09-11160
NUT, LOCKING
8шт.
19
01643-31032
WASHER
8шт.
20
07283-32236
U-BOLT, BOOM TUBES TO BOOM ARM
4шт.
21
426-09-11160
NUT, LOCKING
8шт.
22
01643-31032
WASHER
8шт.
23
FRAME, FRONT (SEE PG 05-002)
-29шт.
24
COVER, FRONT ACCESS (SEE PG 05-002)
-29шт.
25
LIFT ARM (SEE PG 07-002)
-29шт.
