1
416-877-1110
LEVER, ATTACHMENT CONTROL
1шт.
2
113-43-23420
KNOB, CONTROL LEVER
1шт.
3
07020-00900
FITTING, GREASE - CONTROL LEVER
1шт.
4
06120-02016
BEARING, NEEDLE
2шт.
5
06122-02004
SEAL, BEARING
2шт.
6
417-43-18220
PIN, CONTROL LEVER
1шт.
7
419-43-18150
SPACER, CONTROL LEVER
2шт.
8
01010-31070
BOLT, SPACER
2шт.
9
01643-31032
WASHER
2шт.
10
04248-31028
ROD, ATTACHMENT CONTROL LINK
1шт.
11
417-09-12140
JOINT, BALL
1шт.
12
01582-01008
NUT, ADJUSTMENT
1шт.
13
417-09-12160
JOINT, BALL - LH THREAD
1шт.
14
01508-21006
NUT, ADJUSTMENT - LH THREAD
1шт.
15
01643-31032
WASHER
2шт.
16
426-09-11160
NUT
2шт.
17
416-877-1120
LEVER, ATTACHMENT SPOOL CONTROL
1шт.
18
07020-00675
FITTING, GREASE - SPOOL CONTROL
1шт.
19
06120-02016
BEARING, NEEDLE
2шт.
20
06122-02004
SEAL, BEARING
2шт.
21
417-43-18240
LINK, ATTACHMENT SPOOL
2шт.
22
04205-10825
PIN
2шт.
23
04050-12015
PIN, COTTER
2шт.
24
419-43-18160
BOOT, ATTACHMENT CONTROL LEVER
1шт.
25
416-877-1141
PLATE, ATTACHMENT CONTROL LEVER
1шт.
26
416-877-1130
LEVER
1шт.
27
04205-10522
PIN
1шт.
28
04050-11210
PIN, COTTER
1шт.
29
CONTROL VALVE, 3-SPOOL (SEE PG 06-012)
-29шт.
30
LEVER, LOCK (SEE PG 06-054)
-29шт.
