|$0
417-15-12102
FORWARD AND REVERSE CLUTCH ASSEMBLY
1шт.
|$1
417-15-12310
SHAFT AND CYLINDER ASSEMBLY
1шт.
1
NSS
SHAFT, FORWARD AND REVERSE
1шт.
2
NSS
CYLINDER
1шт.
3
NSS
HOUSING
1шт.
4
419-15-12140
RING, SNAP
2шт.
5
419-15-12210
RING, SEAL - FORWARD HOUSING
1шт.
6
419-15-12221
PISTON
1шт.
7
419-15-12190
RING, SEAL - FORWARD PISTON
1шт.
8
7720-50-2590
DISC
8шт.
9
419-15-12310
PLATE, SEPARATE
9шт.
10
419-15-12133
SPRING, WAVE
8шт.
11
419-15-12281
PLATE, END
1шт.
12
419-15-12140
RING, SNAP
1шт.
13
419-15-12240
WASHER, THRUST
4шт.
14
419-15-12250
BEARING, THRUST
2шт.
15
417-15-12231
GEAR, FORWARD
1шт.
16
419-15-12270
BEARING
1шт.
17
419-15-12330
SPACER
1шт.
18
06030-06210
BEARING
1шт.
19
419-15-12121
RING, SEAL - FORWARD AND REVERSE SHAFT
4шт.
|$21
TRANSMISSION SERVICE KIT (SEE PG 02-040)
-29шт.
|$24
-1шт.
|$23
F1 - INCLUDED IN SERVICE KIT 416-15-05121.
-1шт.
|$25
-1шт.
