1
DIVIDER VALVE (SEE PG 04-006)
-29шт.
2
417-875-1790
HOSE, DIVIDER VALVE TO CHECK VALVE
1шт.
3
07371-31049
FLANGE, SPLIT
4шт.
4
07372-21035
BOLT, CHECK VALVE END
4шт.
5
209-09-11130
BOLT, DIVIDER VALVE END
4шт.
6
01643-51032
WASHER
8шт.
7
07000-13032
O-RING
2шт.
8
CHECK VALVE ASSEMBLY (SEE PG 04-008)
-29шт.
9
417-875-1682
BLOCK, MOUNT CHECK VALVES
1шт.
10
01010-51025
BOLT, MOUNT BLOCK
2шт.
11
01643-31032
WASHER
2шт.
12
07000-13035
O-RING
3шт.
13
417-875-1650
BLOCK
1шт.
14
417-875-1710
HOSE, CHECK VALVE TO MAIN PUMP
1шт.
15
07371-31049
FLANGE, SPLIT - CHECK VALVE END
2шт.
16
417-875-1670
BOLT, CHECK VALVE END
4шт.
17
01643-51032
WASHER
4шт.
18
07000-13032
O-RING
1шт.
19
07371-30638
FLANGE, SPLIT - MAIN PUMP END
2шт.
20
01010-30840
BOLT, MAIN PUMP END
4шт.
21
01602-20825
WASHER, LOCK
4шт.
22
07373-10600
SPACER
1шт.
23
07002-13025
O-RING
2шт.
24
PUMP, MAIN HYDRAULIC (SEE PG 06-002)
-29шт.
25
417-875-1720
HOSE, CHECK VALVE TO PRIORITY VALVE
1шт.
26
07371-31049
FLANGE, SPLIT - CHECK VALVE END
2шт.
27
07372-21035
BOLT, CHECK VALVE END
4шт.
28
01643-51032
WASHER
4шт.
29
07000-13032
O-RING
1шт.
30
417-875-1660
ELBOW, PRIORITY VALVE END
1шт.
31
416-62-13730
ELBOW, AT PRIORITY VALVE
1шт.
32
416-62-13450
O-RING
1шт.
33
PRIORITY VALVE (SEE PG 06-024)
-29шт.
