|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$7
416-15-21113
TRANSMISSION ASS'Y
SN: (52935)-UP
1шт.
|$8
0
TRANSMISSION ASS'Y
SN: ((52935)-00054253)
1шт.
|$9
416-15-21111
TRANSMISSION ASS'Y
SN: 53001-(52934)
1шт.
|$$5
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-68A0.
-1шт.
|$11
416-15-21152
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: (52935)-UP
1шт.
|$12
0
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: ((52935)-00054253)
1шт.
|$13
416-15-21150
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: 53001-(52934)
1шт.
|$$9
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-58A0, 59A2, AND F4350-60A0 TO F4350-68A0.
-1шт.
|$17
416-15-12101
CLUTCH ASS'Y,FORWARD AND REVERSE
SN: 53001-UP
1шт.
|$18
417-15-12311
SHAFT
SN: (54324)-UP
1шт.
|$19
417-15-12310
SHAFT ASS'Y
SN: 53001-(54323)
1шт.
1
0
SHAFT,FORWARD AND REVERSE
SN: 53001-UP
1шт.
2
0
CYLINDER
SN: 53001-UP
1шт.
3
0
HOUSING,FORWARD AND REVERSE
SN: 53001-UP
1шт.
4
419-15-12221
PISTON,FORWARD AND REVERSE
SN: 53001-UP
2шт.
5
7720-50-2590
DISC
SN: 53001-UP
12шт.
6
714-16-19730
PLATE,SEPARATE
SN: 53001-UP
14шт.
7
56D-15-12710
SPRING,WAVE
SN: (154633)-UP
12шт.
7
0
SPRING,WAVE
SN: 53001-(154632)
12шт.
8
419-15-12281
PLATE,END
SN: 53001-UP
2шт.
9
419-15-12140
RING,SNAP
SN: 53001-UP
4шт.
10
419-15-12190
RING,SEAL (K1)
SN: 53001-UP
2шт.
11
419-15-12210
RING,SEAL (K1)
SN: 53001-UP
2шт.
12
419-15-12240
WASHER,THRUST
SN: 53001-UP
8шт.
13
419-15-12250
BEARING,THRUST
SN: 53001-UP
4шт.
14
419-15-12271
BEARING
SN: (54076)-UP
3шт.
14
0
BEARING
SN: 53001-(54075)
3шт.
15
419-15-12330
SPACER
SN: 53001-UP
2шт.
16
06030-06210
BEARING
SN: 53001-UP
2шт.
17
417-15-12231
GEAR, 38 TEETH,FORWARD
SN: 53001-UP
1шт.
18
417-15-12243
GEAR, 25 TEETH,REVERSE
SN: 53001-UP
1шт.
19
419-15-12121
RING,SEAL (K1)
SN: 53001-UP
4шт.
