Запчасти Komatsu WA120-3MC FIG. K7-A КОНДИЦ. ВОЗДУХА КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

DAMPER ASSEMBLY (SEE FIG. K0710-03A0)

SN: A31001--UP

1шт.

2

DUCT ASSEMBLY, AIR (SEE FIG. K0710-04A0)

SN: A31001--UP

2шт.

3

425-07-21160

RELAY

SN: A31001--UP

6шт.

4

421-07-21190

CAP

SN: A31001--UP

2шт.

5

421-07-21280

HOSE

SN: A31001--UP

2шт.

6

20Y-979-3120

RECEIVER TANK, RECEIVER

SN: A31001--UP

1шт.

7

AIR CONDITIONER (SEE FIG. K0710-05A0)

SN: A31001--UP

1шт.

8

425-07-21121

CONTROLLER

SN: A31001--UP

1шт.

9

AIR COMPRESSOR ASSEMBLY (SEE FIG. K0710-07A0)

SN: A31001--UP

1шт.

10

CONDENSER ASSEMBLY (SEE FIG. K0710-08A0)

SN: A31001--UP

1шт.
