|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|1
714-11-10003
TRANSMISSION ASS'Y
SN: (68569)-UP
1шт.
|1
714-11-10002
TRANSMISSION ASS'Y
SN: (67311)-(68568)
1шт.
|1
714-11-10001
TRANSMISSION ASS'Y
SN: 63151-(67310)
1шт.
|1
714-11-10000
TRANSMISSION ASS'Y
SN: 63001-63150
1шт.
|1
714-11-10043
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: (68573)-UP
1шт.
|1
714-11-10042
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: (67408)-(68572)
1шт.
|1
714-11-10041
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: 63151-(67407)
1шт.
|1
714-11-10040
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: 63001-63150
1шт.
|$$10
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-67A0.
-1шт.
1
714-11-14520
SHAFT,OUTPUT
SN: 63001-UP
1шт.
2
714-11-14620
GEAR¤ 48 TEETH,OUTPUT
SN: 63001-UP
1шт.
3
04064-06020
RING,SNAP
SN: 63001-UP
1шт.
4
714-11-19360
BEARING
SN: (69310)-UP
1шт.
|4
06002-30210
BEARING
SN: 63001-(69309)
1шт.
5
714-11-19360
BEARING
SN: (69310)-UP
1шт.
|5
06002-30210
BEARING
SN: 63001-(69309)
1шт.
6
714-11-14911
COVER,GEAR
SN: 63001-UP
1шт.
7
01010-81225
BOLT
SN: 63001-UP
2шт.
8
01643-31232
WASHER
SN: 63001-UP
2шт.
9
714-11-14210
COUPLING,FRONT
SN: 63001-UP
1шт.
10
417-15-13770
HOLDER
SN: 63001-UP
1шт.
11
01011-61610
BOLT
SN: 63001-UP
1шт.
12
417-15-13790
O-RING (K1)
SN: 63001-UP
1шт.
13
07012-50065
SEAL,OIL (K1)
SN: (69675)-UP
1шт.
|13
417-15-13690
SEAL,OIL (K1)
SN: 63001-(69674)
1шт.
14
07012-50065
SEAL,OIL (K1)
SN: (69675)-UP
1шт.
|14
417-15-13690
SEAL,OIL (K1)
SN: 63001-(69674)
1шт.
15
417-15-13810
SEAL,DUST (K1)
SN: 63001-UP
1шт.
16
417-15-13810
SEAL,DUST (K1)
SN: 63001-UP
1шт.
17
714-11-18610
HUB,SPLINE
SN: 63001-UP
1шт.
18
714-11-14231
COUPLING,REAR
SN: (170327)-UP
1шт.
|18
714-11-14230
COUPLING,REAR
SN: 63001-(170326)
1шт.
19
714-11-14271
SHIM¤ 0.05MM
SN: 63001-UP
3шт.
|19
714-11-14281
SHIM¤ 0.20MM
SN: 63001-UP
2шт.
|19
714-11-14291
SHIM¤ 0.50MM
SN: 63001-UP
3шт.
|19
714-11-14371
SHIM¤ 0.05MM
SN: 63001-UP
3шт.
|19
714-11-14381
SHIM¤ 0.20MM
SN: 63001-UP
2шт.
|19
714-11-14391
SHIM¤ 0.50MM
SN: 63001-UP
3шт.
