|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|1
714-11-10003
TRANSMISSION ASS'Y
SN: (68569)-UP
1шт.
|1
714-11-10002
TRANSMISSION ASS'Y
SN: (67311)-(68568)
1шт.
|1
714-11-10001
TRANSMISSION ASS'Y
SN: 63151-(67310)
1шт.
|1
714-11-10000
TRANSMISSION ASS'Y
SN: 63001-63150
1шт.
|1
714-11-10043
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: (68573)-UP
1шт.
|1
714-11-10042
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: (67408)-(68572)
1шт.
|1
714-11-10041
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: 63151-(67407)
1шт.
|1
714-11-10040
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: 63001-63150
1шт.
|$$10
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-67A0.
-1шт.
|1
714-11-12020
CLUTCH ASS'Y,FORWARD AND 2ND
SN: 63001-UP
1шт.
|1
714-11-12141
SHAFT ASS'Y
SN: 63001-UP
1шт.
1
0
SHAFT
SN: 63001-UP
1шт.
2
0
HOUSING ASS'Y
SN: 63001-UP
1шт.
3
714-11-12650
PISTON,FORWARD
SN: 63001-UP
1шт.
4
714-11-12660
PISTON,2ND
SN: 63001-UP
1шт.
5
714-08-19710
DISC
SN: 63001-UP
14шт.
6
714-08-19730
PLATE,SEPARATE
SN: 63001-UP
16шт.
7
714-08-12910
SPRING,WAVE
SN: 63001-UP
14шт.
8
714-08-12610
PLATE,END
SN: 63001-UP
2шт.
9
714-08-19510
RING,SNAP
SN: 63001-UP
2шт.
10
714-08-19210
RING,SEAL
SN: 63001-UP
2шт.
11
714-11-19240
RING,SEAL
SN: 63001-UP
1шт.
12
714-11-19230
RING,SEAL
SN: 63001-UP
1шт.
13
714-11-19510
WASHER,THRUST
SN: 63001-UP
4шт.
14
714-11-12710
SPACER
SN: 63001-UP
2шт.
15
419-15-12271
BEARING
SN: (68893)-UP
3шт.
|15
0
BEARING,NEEDLE
SN: 63001-(68892)
3шт.
16
714-11-12430
GEAR¤ 47 TEETH,FORWARD
SN: 63001-UP
1шт.
17
714-11-12440
GEAR¤ 27-49 TEETH,2ND
SN: 63001-UP
1шт.
18
06040-06210
BEARING
SN: 63001-UP
1шт.
19
06040-06310
BEARING
SN: 63001-UP
1шт.
20
419-15-12122
RING,SEAL
SN: 63001-UP
3шт.
