|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|1
714-11-10002
TRANSMISSION ASS'Y
SN: (67311)-@
1шт.
|1
714-11-10001
TRANSMISSION ASS'Y
SN: 63151-(67310)
1шт.
|1
714-11-10000
TRANSMISSION ASS'Y
SN: 63001-63150
1шт.
|1
714-11-10042
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: (67408)-@
1шт.
|1
714-11-10041
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: 63151-(67407)
1шт.
|1
714-11-10040
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: 63001-63150
1шт.
|$$8
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-67A0.
-1шт.
|1
714-11-15020
CONTROL VALVE ASS'Y
SN: (66916)-(67748)
1шт.
|1
714-11-15011
CONTROL VALVE ASS'Y
SN: (66468)-(66915)
1шт.
|1
714-11-15010
CONTROL VALVE ASS'Y
SN: 63001-(66467)
1шт.
|$$12
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-60A0 TO F4350-62A0.
-1шт.
|1
714-11-16101
VALVE ASS'Y,LOWER
SN: (67036)-(67748)
1шт.
|1
714-11-16100
VALVE ASS'Y,LOWER
SN: 63001-(67035)
1шт.
|$$15
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F4350-61A0 AND F4350-62A0.
-1шт.
|1
714-11-16701
SOLENOID VALVE A.
SN: (67036)-(67748)
1шт.
|1
714-11-16700
SOLENOID VALVE A.
SN: 63001-(67035)
1шт.
|1
714-11-16720
BODY ASS'Y
SN: 63001-(67748)
1шт.
1
0
BODY,SOLENOID
SN: 63001-(67748)
1шт.
2
04260-00635
BALL
SN: 63001-(67748)
5шт.
3
419-15-16751
VALVE,MANUAL
SN: 63001-(67748)
1шт.
4
415-15-15470
PLUG
SN: 63001-(67748)
1шт.
5
07000-02010
O-RING (K2)
SN: 63001-(67748)
1шт.
6
17A-15-17271
SOLENOID VALVE
SN: (67036)-(67748)
4шт.
|6
714-10-16951
VALVE ASS'Y,SOLENOID
SN: 63001-(67035)
4шт.
7
561-15-47221
BODY
SN: (67036)-(67748)
1шт.
|7
714-10-16960
O-RING (K2)
SN: 63001-(67035)
1шт.
8
561-15-47230
SCREEN
SN: (67036)-(67748)
1шт.
|8
714-10-16970
O-RING (K2)
SN: 63001-(67035)
1шт.
9
01220-40412
SCREW
SN: 63001-(67748)
16шт.
10
07043-70108
PLUG
SN: 63001-(67748)
6шт.
11
419-15-15640
PLUG
SN: 63001-(67748)
2шт.
12
714-11-16810
PLATE
SN: 63001-(67748)
1шт.
13
01010-80816
BOLT
SN: 63001-@
2шт.
14
01643-30823
WASHER
SN: 63001-@
2шт.
15
01011-81005
BOLT
SN: 63001-(67748)
2шт.
16
01011-81010
BOLT
SN: 63001-(67748)
1шт.
17
01011-81025
BOLT
SN: 63001-(67748)
6шт.
18
01011-81030
BOLT
SN: 63001-(67748)
1шт.
19
419-15-16670
PLATE,LOCK
SN: 63001-(67748)
1шт.
20
01643-31032
WASHER
SN: 63001-(67748)
2шт.
21
419-06-12840
PLATE
SN: 63001-@
1шт.
22
07043-70108
PLUG
SN: 63001-@
1шт.
23
419-15-16811
GASKET,UPPER (K2)
SN: 63001-@
1шт.
24
01010-80860
BOLT
SN: 63001-@
1шт.
25
01010-80875
BOLT
SN: 63001-@
1шт.
26
419-15-16660
FILTER ASS'Y
SN: 63001-@
1шт.
|26
419-15-16930
ELEMENT
SN: 63001-@
1шт.
|26
419-15-16940
HEAD
SN: 63001-@
1шт.
|26
419-15-16950
O-RING
SN: 63001-@
1шт.
|26
419-15-16960
CASE,FILTER
SN: 63001-@
1шт.
27
07000-02014
O-RING (K2)
SN: 63001-@
2шт.
28
01010-81035
BOLT
SN: 63001-@
2шт.
29
01602-01030
WASHER,SPRING
SN: 63001-@
2шт.
30
01642-21016
WASHER
SN: 63001-@
2шт.
