|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|1
714-11-10003
TRANSMISSION ASS'Y
SN: (68569)-UP
1шт.
|1
714-11-10002
TRANSMISSION ASS'Y
SN: (67311)-(68568)
1шт.
|1
714-11-10001
TRANSMISSION ASS'Y
SN: 63151-(67310)
1шт.
|1
714-11-10000
TRANSMISSION ASS'Y
SN: 63001-63150
1шт.
|1
714-11-10043
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: (68573)-UP
1шт.
|1
714-11-10042
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: (67408)-(68572)
1шт.
|1
714-11-10041
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: 63151-(67407)
1шт.
|1
714-11-10040
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: 63001-63150
1шт.
|$$10
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-67A0.
-1шт.
1
07030-00252
BREATHER
SN: 63001-UP
1шт.
2
419-15-18241
PLUG
SN: 63001-UP
1шт.
3
07002-02434
O-RING (K1)
SN: 63001-UP
1шт.
4
419-15-18251
RING,SNAP
SN: 63001-UP
1шт.
5
09608-05080
PLATE¤ NAME,(LIMITED SUPPLY)
SN: 63001-UP
1шт.
6
04418-13060
SCREW
SN: 63001-UP
4шт.
7
714-11-11350
RETAINER
SN: 63001-UP
1шт.
|7
714-11-11340
COVER,(FOR EMERGENCY STEERING)
SN: 63001-UP
1шт.
8
07000-02085
O-RING (K1)
SN: 63001-UP
1шт.
9
01010-81230
BOLT
SN: 63001-UP
3шт.
10
714-11-14690
WORM
SN: 63001-UP
1шт.
|10
714-11-14680
WORM,(FOR EMERGENCY STEERING)
SN: 63001-UP
1шт.
11
04065-01910
RING,SNAP
SN: 63001-UP
1шт.
12
714-11-14670
GEAR
SN: 63001-UP
1шт.
13
714-07-18660
SLEEVE
SN: 63001-UP
1шт.
14
07002-02434
O-RING (K1)
SN: 63001-UP
1шт.
15
01252-30816
BOLT
SN: 63001-UP
1шт.
16
01643-30823
WASHER
SN: 63001-UP
1шт.
17
714-11-18990
PLATE
SN: 63001-UP
1шт.
18
01010-81245
BOLT
SN: 63001-UP
1шт.
19
01643-31232
WASHER
SN: 63001-UP
1шт.
20
714-11-16880
PLATE
SN: (67991)-UP
1шт.
