1
AIR CONDITIONER ASSEMBLY (SEE PG 05-118)
-29шт.
|$44
-1шт.
|$2
LINE - ENGINE TO AIR CONDITIONER:
-1шт.
2
09483-30450
HOSE, ELBOW - AT AIR CONDITIONER UNIT
1шт.
3
07281-00259
CLAMP, HOSE
4шт.
4
417-963-2840
CONNECTOR, AT AIR CONDITIONER UNIT
1шт.
5
09483-10536
HOSE, ENGINE TO HEATER UNIT
1шт.
6
416-942-1130
ELBOW, AT ENGINE
1шт.
|$45
-1шт.
|$9
LINE - AIR CONDITIONER TO RADIATOR:
-1шт.
7
09483-30450
HOSE, ELBOW - AT AIR CONDITIONER UNIT
1шт.
8
07281-00259
CLAMP, HOSE
4шт.
9
417-963-2840
CONNECTOR, AT AIR CONDITIONER UNIT
1шт.
10
09483-10532
HOSE, HEATER UNIT TO RADIATOR
1шт.
11
416-942-1543
ELBOW, AT RADIATOR WATER TUBE
1шт.
11A
TUBE, RADIATOR TO WATER PUMP (SEE PG 01-042)
-29шт.
|$46
-1шт.
|$17
AIR CONDITIONER DRAIN LINES:
-1шт.
12
417-963-3160
HOSE, DRAIN
2шт.
13
07281-00259
CLAMP, HOSE
2шт.
|$47
-1шт.
|$21
LINE HOLDING DEVICES:
-1шт.
14
417-963-2730
PLATE, HEATER LINES
1шт.
15
417-963-2740
PLATE, HEATER LINES
1шт.
16
01010-50820
BOLT, PLATES
2шт.
17
01643-30823
WASHER
2шт.
18
421-07-11760
CLIP, HEATER HOSES
4шт.
19
01435-01016
BOLT, HEATER HOSE CLIP
1шт.
20
01010-31270
BOLT, HEATER HOSE CLIP
1шт.
21
01643-31232
WASHER
1шт.
22
421-64-15110
SPACER
1шт.
23
01010-51220
BOLT, HEATER HOSE CLIP
2шт.
24
01643-31232
WASHER
2шт.
25
416-942-1860
BRACKET, HOSE CLIP TO HOOD
1шт.
26
01010-51020
BOLT, BRACKET
1шт.
27
01643-31032
WASHER
1шт.
28
08034-00536
STRAP, TIE
3шт.
29
416-942-1871
PLATE, DRAIN HOSES
1шт.
30
417-963-2790
PLATE, DRAIN HOSES
1шт.
31
01010-50820
BOLT, PLATES
2шт.
32
01643-30823
WASHER
4шт.
33
175-06-25160
CLIP, DRAIN HOSE
3шт.
34
01010-51016
BOLT, DRAIN HOSE CLIP
2шт.
35
01643-31032
WASHER
2шт.
