1
07260-04120
HOSE, RESERVOIR TO PUMP
1шт.
2
07281-00609
CLAMP
4шт.
3
417-62-13123
TUBE, RESERVOIR TO PUMP
1шт.
4
07000-13045
O-RING
1шт.
5
01010-31280
BOLT, MOUNT TUBE TO PUMP
4шт.
6
01602-21236
WASHER, SPRING
4шт.
7
PUMP ASSEMBLY (SEE PG 06-002)
-29шт.
8
07000-02105
O-RING
1шт.
9
01010-31235
BOLT, MOUNT PUMP
2шт.
10
01643-31232
WASHER
2шт.
11
417-62-13831
HOSE, PUMP TO PRIORITY VALVE
1шт.
12
416-62-13411
HOSE, PUMP TO PRIORITY VALVE
1шт.
|$12
HOSE, PUMP TO CHECK VALVE (SEE PG 04-018)
-29шт.
13
07373-10600
SPACER
2шт.
14
07000-13025
O-RING
1шт.
14A
07002-13025
O-RING
3шт.
15
07371-30638
FLANGE
4шт.
16
01010-30840
BOLT
8шт.
17
01602-20825
WASHER, SPRING
8шт.
18
07230-20522
UNION
1шт.
19
07002-12434
O-RING
1шт.
20
416-62-13420
ELBOW, AT PRIORITY VALVE
1шт.
21
416-62-13450
O-RING
1шт.
22
PRIORITY VALVE (SEE PG 06-040)
-29шт.
23
416-64-15600
BOLT, MOUNT PRIORITY VALVE
2шт.
24
01643-30823
WASHER
2шт.
25
415-62-13841
ELBOW
1шт.
26
416-62-13450
O-RING
1шт.
27
CHECK VALVE (SEE PG 06-038)
-29шт.
28
416-62-13450
O-RING
1шт.
29
417-62-13920
TEE
1шт.
30
416-62-13450
O-RING
1шт.
31
417-62-13931
HOSE, PRIORITY VALVE TO CONTROL VALVE
1шт.
32
07230-11034
UNION
1шт.
33
07002-13334
O-RING
1шт.
34
CONTROL VALVE, 2-SPOOL (SEE PG 06-016)
-29шт.
|$36
CONTROL VALVE, 3-SPOOL (SEE PG 06-020)
-29шт.
35
417-64-13114
BRACKET, CONTROL VALVE MOUNTING
1шт.
36
417-64-13123
BRACKET, CONTROL VALVE MOUNTING
1шт.
37
01010-31025
BOLT, CONTROL VALVE MOUNTING
4шт.
38
01643-31032
WASHER
4шт.
39
417-62-14130
SPACER
4шт.
40
419-43-17930
CUSHION, CONTROL VALVE MOUNTING BRACKET
4шт.
41
417-62-13620
CUSHION, CONTROL VALVE MOUNTING BRACKET
4шт.
42
419-43-17920
WASHER
8шт.
43
01010-31250
BOLT, CONTROL VALVE MOUNTING BRACKET
4шт.
44
416-64-15640
WASHER, PRIORITY VALVE MOUNTING
2шт.
45
416-64-15630
CUSHION, PRIORITY VALVE MOUNTING
2шт.
46
426-09-11140
NUT, PRIORITY VALVE MOUNTING
2шт.
|$54
-1шт.
|$50
F1 - ON MACHINES NOT EQUIPPED WITH GROUND DRIVEN
-1шт.
|$51
STEERING.
-1шт.
|$55
-1шт.
|$53
F2 - ON MACHINES EQUIPPED WITH GROUND DRIVEN STEERING.
-1шт.
|$56
-1шт.
