1
HARNESS, FRONT (SEE PG 01-052)
-29шт.
2
08037-03620
GROMMET
2шт.
3
08036-01414
CLIP
1шт.
|$3
01435-01016
BOLT
1шт.
4
08036-11214
CLIP
4шт.
5
08035-03014
CLIP
4шт.
6
417-U77-1911
HARNESS, PARALLEL TOOL CARRIER
1шт.
7
08034-00519
STRAP, TIE
-2шт.
8
RELAY, BATTERY (SEE PG 01-060)
-29шт.
9
417-54-13510
GROMMET
1шт.
10
08036-10814
CLIP
2шт.
11
416-879-1670
HARNESS, INLINE FUSE
1шт.
12
08051-00801
CLIP
1шт.
13
416-S28-2230
SWITCH, DUMP SPEED
1шт.
14
416-S28-2230
SWITCH, BUCKET / FORK CONTROL
1шт.
15
417-879-2230
SWITCH, MULTI-COUPLER
1шт.
16
417-U77-1950
BRACKET, CONTROL SWITCHES
1шт.
17
417-U77-1870
PRODUCT GRAPHIC, ATTACHMENT - BUCKET / FORK
1шт.
18
417-U77-1880
PRODUCT GRAPHIC, DUMP SPEED
1шт.
19
417-U77-1890
PRODUCT GRAPHIC, QUICK COUPLER
1шт.
20
BRACKET, LIMIT SWITCH MOUNTING (SEE PG 06-074)
-29шт.
21
08076-50350
SWITCH, LIMIT
1шт.
|$22
01435-01030
BOLT, MOUNT LIMIT SWITCH
2шт.
22
08053-01510
CLIP
1шт.
23
LEVER (SEE PG 06-074)
-29шт.
24
LEVER, WORK EQUIPMENT CONTROL (SEE PG 06-074)
-29шт.
25
417-U77-1940
PLATE, RELAY MOUNTING
1шт.
|$27
01435-01016
BOLT
2шт.
26
569-06-61960
RELAY, PROXIMITY SWITCH
2шт.
|$29
01435-00612
BOLT
2шт.
27
417-U77-1921
HARNESS, FRONT HARNESS TO BUCKET LEVELER RELAY
1шт.
28
417-U77-1931
HARNESS, FRONT HARNESS TO BOOM KICK-OUT
1шт.
29
08053-01510
CLIP
1шт.
|$33
01435-01016
BOLT
1шт.
30
08036-01014
CLIP
6шт.
|$35
01435-01016
BOLT
5шт.
31
423-06-12640
CLIP
1шт.
|$37
01435-01016
BOLT
1шт.
32
SWITCH, BOOM KICK-OUT (SEE PG 06-082)
-29шт.
33
08052-11911
CLIP
2шт.
|$40
01435-01016
BOLT
2шт.
34
SWITCH, BUCKET LEVELER (SEE PG 06-082)
-29шт.
35
VALVE, CONTROL - MULTI-COUPLER (SEE PG 06-044)
-29шт.
|$43
01252-40635
BOLT, MOUNT VALVE
4шт.
|$44
01643-30623
WASHER
4шт.
|$45
01596-00606
NUT
4шт.
36
416-879-1530
BRACKET, CONTROL VALVE
1шт.
|$47
01010-81030
BOLT, MOUNT BRACKET
2шт.
