417-15-18103
CASE ASSEMBLY, REAR (TRANSMISSION)
1шт.
1
NSS
CASE
1шт.
2
NSS
SHAFT, IDLER
1шт.
3
417-15-12823
GEAR, IDLER
1шт.
4
06033-06211
BEARING
2шт.
5
04064-05520
RING SNAP
1шт.
6
419-15-18240
PLUG, OIL DRAIN
1шт.
7
07002-02434
O-RING, OIL DRAIN PLUG
1шт.
8
419-15-18251
RING, SNAP
1шт.
9
417-15-14140
COVER
1шт.
10
07000-05200
O-RING, COVER
1шт.
11
01010-31235
BOLT
6шт.
12
01643-31232
WASHER
6шт.
13
04020-01434
PIN
2шт.
14
417-15-13452
COVER, SPEEDOMETER PICK-UP
1шт.
|$15
419-15-14231
COVER
1шт.
15
01010-31235
BOLT, COVER
2шт.
|$17
01010-31230
BOLT, COVER
2шт.
16
01643-31232
WASHER
2шт.
17
07000-02075
O-RING, COVER
1шт.
18
417-15-13460
BUSHING
1шт.
19
417-15-13511
GEAR, WORM
1шт.
20
417-15-13530
GEAR, SPEEDOMETER
1шт.
21
07002-02434
O-RING, SPEEDOMETER SLEEVE
1шт.
22
417-15-13432
SLEEVE, SPEEDOMETER PICK-UP
1шт.
23
01010-31235
BOLT, MOUNT REAR CASE
12шт.
24
01010-31240
BOLT, MOUNT REAR CASE
1шт.
25
22X-22-13171
PLATE, NAME (LIMITED SUPPLY)
1шт.
26
04418-03060
SCREW
4шт.
27
417-15-18190
FILLER, OIL
1шт.
|$30
417-879-1540
FILLER, OIL
1шт.
28
07000-02065
O-RING, FILLER
1шт.
|$32
07000-12065
O-RING, FILLER
1шт.
29
01010-31040
BOLT
4шт.
30
01643-31032
WASHER
4шт.
31
6136-21-7190
CHAIN, FILLER CAP
1шт.
32
6136-21-7120
CAP, FILLER
1шт.
|$37
6136-21-7180
GASKET, FILLER CAP
1шт.
33
417-15-14432
GAUGE, OIL LEVEL
1шт.
|$39
419-15-18131
GASKET, LIQUID (NOT SHOWN)
-2шт.
|$40
TRANSMISSION SERVICE KIT (SEE PG 02-048)
-29шт.
|$59
-1шт.
|$42
F1 - INCLUDED IN SERVICE KIT 416-15-05121.
-1шт.
|$60
-1шт.
|$61
-1шт.
|$45
F2 - ON MACHINES NOT EQUIPPED WITH GROUND DRIVEN
-1шт.
|$46
STEERING. FOR MACHINES EQUIPPED WITH GROUND
-1шт.
|$47
DRIVEN STEERING SEE PG 04-019.
-1шт.
|$62
-1шт.
|$49
F3 - ON MACHINES EQUIPPED WITH SPEEDOMETER.
-1шт.
|$63
-1шт.
|$64
-1шт.
|$52
F4 - ON MACHINES NOT EQUIPPED WITH SPEEDOMETER.
-1шт.
|$65
-1шт.
|$66
-1шт.
|$55
F5 - USED ON MACHINES WITH STANDARD LOADER LINKAGE.
-1шт.
|$67
-1шт.
|$68
-1шт.
|$58
F6 - USED ON MACHINES WITH PARALLEL TOOL CARRIER LINKAGE.
-1шт.
|$69
-1шт.
