|$1
417-22-20050
AXLE ASS'Y,FRONT (LIMITED SLIP DIFF.)
SN: 53001-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4400-01A0 TO F4400-05A0.
-1шт.
1
417-22-21230
COUPLING
SN: 53001-UP
1шт.
2
417-22-21310
PROTECTOR
SN: 53001-UP
1шт.
|$8
417-22-27160
PINION ASS'Y
SN: 53001-UP
1шт.
3
0
GEAR
SN: 53001-UP
1шт.
4
0
PINION
SN: 53001-UP
1шт.
5
417-22-11810
BEARING
SN: 53001-UP
1шт.
6
417-22-21130
CAGE
SN: 53001-UP
1шт.
7
417-22-11820
BEARING
SN: 53001-UP
1шт.
8
417-22-11860
SPACER
SN: 53001-UP
1шт.
9
07012-00065
SEAL
SN: 53001-UP
1шт.
10
417-22-21760
SEAL
SN: 53001-UP
1шт.
11
417-15-13770
HOLDER
SN: 53001-UP
1шт.
12
01011-61615
BOLT
SN: 53001-UP
1шт.
13
07000-13035
O-RING
SN: 53001-UP
1шт.
14
07000-15160
O-RING
SN: 53001-UP
1шт.
15
417-22-11360
SHIM, 0.05MM
SN: 53001-UP
2шт.
15
417-22-11370
SHIM, 0.2MM
SN: 53001-UP
2шт.
15
417-22-11380
SHIM, 0.3MM
SN: 53001-UP
2шт.
15
417-22-11390
SHIM, 0.8MM
SN: 53001-UP
1шт.
16
01010-31235
BOLT
SN: 53001-UP
6шт.
17
01643-31232
WASHER
SN: 53001-UP
6шт.
|$28
417-22-27101
DIFFERENTIAL
SN: 54447-UP
1шт.
|$29
417-22-27100
DIFFERENTIAL
SN: 53001-54446
1шт.
18
417-22-27110
CASE
SN: 53001-UP
1шт.
19
417-22-27210
RING,PRESSURE
SN: 53001-UP
2шт.
20
417-22-27220
SHAFT
SN: 53001-UP
1шт.
21
417-22-27310
PINION
SN: 53001-UP
4шт.
22
417-22-27320
GEAR
SN: 53001-UP
2шт.
23
417-22-27411
DISC
SN: 54447-UP
4шт.
23
417-22-27410
DISC
SN: 53001-54446
4шт.
24
417-22-27450
PLATE
SN: 53001-UP
4шт.
25
417-22-27460
PLATE
SN: 53001-UP
4шт.
26
417-22-27370
WASHER
SN: 53001-UP
2шт.
27
417-22-27380
WASHER
SN: 53001-UP
2шт.
|$41
417-22-27201
DIFFERENTIAL ASS'Y,(FOR SHIPPING)
SN: 54447-UP
1шт.
|$42
417-22-27200
DIFFERENTIAL ASS'Y,(FOR SHIPPING)
SN: 53001-54446
1шт.
28
417-22-27101
DIFFERENTIAL,(FOR SHIPPING)
SN: 54447-UP
1шт.
28
417-22-27100
DIFFERENTIAL,(FOR SHIPPING)
SN: 53001-54446
1шт.
29
417-22-27190
COVER,(FOR SHIPPING)
SN: 53001-UP
1шт.
30
01010-31625
BOLT,(FOR SHIPPING)
SN: 53001-UP
4шт.
31
01010-31640
BOLT
SN: 53001-UP
16шт.
32
417-22-11850
BEARING
SN: 53001-UP
2шт.
33
417-22-13113
HOUSING
SN: 53001-UP
1шт.
34
07044-13620
PLUG
SN: 53001-UP
1шт.
35
07002-13634
O-RING
SN: 53001-UP
1шт.
36
419-22-13140
PLUG
SN: 53001-UP
2шт.
37
07002-13034
O-RING
SN: 53001-UP
2шт.
38
07043-70211
PLUG
SN: 53001-UP
2шт.
39
419-33-11460
BLEEDER
SN: 53001-UP
2шт.
40
07040-11209
PLUG
SN: 53001-UP
2шт.
41
07002-11223
O-RING
SN: 53001-UP
2шт.
42
417-22-13121
COVER
SN: 53001-UP
1шт.
43
01010-31230
BOLT
SN: 53001-UP
16шт.
44
01643-31232
WASHER
SN: 53001-UP
16шт.
45
566-32-11620
CAP
SN: 53001-UP
2шт.
46
417-22-11162
CARRIER
SN: 53001-UP
2шт.
47
417-22-11461
SHIM, 0.07MM
SN: 53001-UP
2шт.
47
417-22-11471
SHIM, 0.2MM
SN: 53001-UP
2шт.
47
417-22-11481
SHIM, 0.3MM
SN: 53001-UP
2шт.
47
417-22-11491
SHIM, 0.8MM
SN: 53001-UP
2шт.
48
417-33-11430
RING
SN: 53001-UP
2шт.
49
01010-31230
BOLT
SN: 53001-UP
12шт.
50
417-33-11420
O-RING
SN: 53001-UP
2шт.
