|$0
TRANSMISSION ASSEMBLY(SEE FIG. F4350-51A0)
SN: A80001-A80135-UP
-1шт.
|$2
OR
-1шт.
|$4
TRANSMISSION ASSEMBLY(SEE FIG. F4350-51A0)
SN: A80136-UP-UP
-1шт.
1
714-11-14520
SHAFT, OUTPUT
SN: A80001-UP-UP
1шт.
2
714-11-14620
GEAR, OUTPUT - 48 TEETH
SN: A80001-UP-UP
1шт.
3
04064-06020
RING, SNAP
SN: A80001-UP-UP
1шт.
4
06002-30210
BEARING
SN: A80001-UP-UP
1шт.
5
06002-30210
BEARING
SN: A80001-UP-UP
1шт.
6
714-11-14911
COVER, GEAR
SN: A80001-UP-UP
1шт.
7
01010-E1225
BOLT
SN: A80001-UP-UP
2шт.
8
01643-31232
WASHER
SN: A80001-UP-UP
2шт.
9
714-11-14210
COUPLING, FRONT
SN: A80001-UP-UP
1шт.
10
417-15-13770
HOLDER
SN: A80001-UP-UP
1шт.
11
01011-61610
BOLT
SN: A80001-UP-UP
1шт.
12
417-15-13790
O-RING
SN: A80001-UP-UP
1шт.
13
417-15-13690
SEAL, OIL
SN: A80001-UP-UP
1шт.
14
417-15-13690
SEAL, OIL
SN: A80001-UP-UP
1шт.
15
417-15-13810
SEAL, DUST
SN: A80001-UP-UP
1шт.
16
417-15-13810
SEAL, DUST
SN: A80001-UP-UP
1шт.
17
714-11-18610
HUB, SPLINE
SN: A80001-UP-UP
1шт.
18
714-11-14231
COUPLING, REAR
SN: A80001-UP-UP
1шт.
19
714-11-14271
SHIM - 0.002 IN. (0.05 MM)
SN: A80001-UP-UP
3шт.
|$24
714-11-14281
SHIM - 0.008 IN. (0.20 MM)
SN: A80001-UP-UP
2шт.
|$25
714-11-14291
SHIM - 0.020 IN. (0.50 MM)
SN: A80001-UP-UP
3шт.
|$26
714-11-14371
SHIM - 0.002 IN. (0.05 MM)
SN: A80001-UP-UP
3шт.
|$27
714-11-14381
SHIM - 0.008 IN. (0.20 MM)
SN: A80001-UP-UP
2шт.
|$28
714-11-14391
SHIM - 0.020 IN. (0.50 MM)
SN: A80001-UP-UP
3шт.
20
HOUSING (SEE FIG. F4350-51A0)
SN: A80001-UP-UP
-1шт.
