|$0
AXLE ASSEMBLY, REAR(SEE FIG. F4500-01A0)
SN: A80001-UP-UP
-1шт.
1
417-22-21230
COUPLING
SN: A80001-UP-UP
1шт.
2
417-15-13770
HOLDER
SN: A80001-UP-UP
1шт.
3
01011-61615
BOLT
SN: A80001-UP-UP
1шт.
4
07012-00065
SEAL
SN: A80001-UP-UP
1шт.
5
417-22-21760
SEAL
SN: A80001-UP-UP
1шт.
6
417-22-11810
BEARING
SN: A80001-UP-UP
1шт.
7
417-22-11820
BEARING
SN: A80001-UP-UP
1шт.
8
417-22-11860
SPACER
SN: A80001-UP-UP
1шт.
9
417-22-21310
PROTECTOR
SN: A80001-UP-UP
1шт.
10
07000-13035
O-RING
SN: A80001-UP-UP
1шт.
11
417-23-21130
CAGE
SN: A80001-UP-UP
1шт.
|$12
417-22-21200
PINION ASSEMBLY
SN: A80001-UP-UP
1шт.
12
NSS
GEAR
SN: A80001-UP-UP
1шт.
13
NSS
PINION, BEVEL
SN: A80001-UP-UP
1шт.
14
417-22-11360
SHIM - 0.002 IN. (0.05 MM)
SN: A80001-UP-UP
2шт.
|$16
417-22-11370
SHIM - 0.008 IN. (0.20 MM)
SN: A80001-UP-UP
2шт.
|$17
417-22-11380
SHIM - 0.012 IN. (0.30 MM)
SN: A80001-UP-UP
2шт.
|$18
417-22-11390
SHIM - 0.031 IN. (0.80 MM)
SN: A80001-UP-UP
1шт.
15
07000-15160
O-RING
SN: A80001-UP-UP
1шт.
16
01010-61235
BOLT
SN: A80001-UP-UP
13шт.
17
01643-31232
WASHER
SN: A80001-UP-UP
13шт.
18
417-22-11513
CARRIER
SN: A80001-UP-UP
1шт.
19
417-22-11432
GEAR
SN: A80001-UP-UP
2шт.
20
417-22-11420
PINION
SN: A80001-UP-UP
4шт.
21
417-22-11410
SHAFT
SN: A80001-UP-UP
4шт.
22
417-22-11530
WASHER
SN: A80001-UP-UP
1шт.
23
417-22-11442
PIN
SN: A80001-UP-UP
4шт.
24
01010-61645
BOLT
SN: A80001-UP-UP
12шт.
25
417-22-11850
BEARING
SN: A80001-UP-UP
2шт.
26
417-23-13112
HOUSING
SN: A80001-UP-UP
1шт.
27
07044-13620
PLUG
SN: A80001-UP-UP
1шт.
28
07002-13634
O-RING
SN: A80001-UP-UP
1шт.
29
419-22-13140
PLUG
SN: A80001-UP-UP
2шт.
30
07002-13034
O-RING
SN: A80001-UP-UP
2шт.
31
07043-70211
PLUG
SN: A80001-UP-UP
2шт.
32
419-33-11460
BLEEDER
SN: A80001-UP-UP
2шт.
33
07040-11209
PLUG
SN: A80001-UP-UP
2шт.
34
07002-11223
O-RING
SN: A80001-UP-UP
2шт.
35
417-22-13121
COVER
SN: A80001-UP-UP
1шт.
36
01010-61230
BOLT
SN: A80001-UP-UP
16шт.
37
01643-31232
WASHER
SN: A80001-UP-UP
16шт.
38
566-32-11620
CAP
SN: A80001-UP-UP
2шт.
39
417-22-11162
CARRIER
SN: A80001-UP-UP
2шт.
40
417-22-11461
SHIM - 0.003 IN. (0.07 MM)
SN: A80001-UP-UP
2шт.
|$45
417-22-11471
SHIM - 0.008 IN. (0.20 MM)
SN: A80001-UP-UP
2шт.
|$46
417-22-11481
SHIM - 0.012 IN. (0.30 MM)
SN: A80001-UP-UP
2шт.
|$47
417-22-11491
SHIM - 0.031 IN. (0.80 MM)
SN: A80001-UP-UP
2шт.
41
417-33-11430
RING
SN: A80001-UP-UP
2шт.
42
01010-61230
BOLT
SN: A80001-UP-UP
12шт.
43
417-33-11420
O-RING
SN: A80001-UP-UP
2шт.
44
SHAFT (SEE FIG. F4500-01A0)
SN: A80001-UP-UP
-1шт.
