|$0
AIR CONDITIONER KIT(SEE FIG. K0710-01A0)
SN: A80001-UP-UP
-1шт.
|$2
OR
-1шт.
|$4
HEATER ASSEMBLY(SEE FIG. K0710-01A1)
SN: A80001-UP-UP
-1шт.
1
444 034
ADAPTER
SN: A80001-UP-UP
1шт.
2
419-963-AE10
VALVE, SHUT-OFF
SN: A80001-UP-UP
2шт.
3
HOSE, OUTLET - 43 IN.
SN: A80001-UP-UP
-2шт.
4
07281-00259
CLAMP, HOSE
SN: A80001-UP-UP
6шт.
5
08036-02514
CLIP, HOSE
SN: A80001-UP-UP
2шт.
6
417-54-13470
SPACER
SN: A80001-UP-UP
1шт.
7
HOSE, INLET - 15 IN.
SN: A80001-UP-UP
-2шт.
8
419-963-A150
VALVE, WATER - EARLIER VERSION
SN: A80001-A80338-UP
1шт.
|$14
OR
-1шт.
8
VALVE, WATER - CURRENT VERSION (SEE FIG. K0710-07A1)
SN: A80339-UP-UP
-1шт.
9
HOSE, INLET - 12 IN.
SN: A80001-UP-UP
-2шт.
10
25 222 R1
BOLT
SN: A80001-UP-UP
1шт.
11
421-07-23950
PLATE
SN: A80001-UP-UP
1шт.
12
421-07-23960
SHEET
SN: A80001-UP-UP
1шт.
13
01435-00610
BOLT
SN: A80001-UP-UP
2шт.
14
01435-01016
BOLT
SN: A80001-UP-UP
1шт.
15
01435-01225
BOLT
SN: A80001-UP-UP
1шт.
16
115 224
REDUCER
SN: A80001-UP-UP
1шт.
|$25
364 359 C1
HOSE, BULK
SN: A80001-UP-UP
-2шт.
|$26
-1шт.
|$27
F1 - PART OF A/C HARDWARE KIT. (SEE FIG. K0710-01A0)
-1шт.
|$29
-1шт.
|$30
F2 - REORDER VALVE KIT P/N 1312 034 H91.
-1шт.
|$32
-1шт.
|$33
F3 - CUT TO FIT FROM BULK HEATER HOSE.
-1шт.
|$34
-1шт.
