|$0
714-11-10040
TRANSMISSION ASSEMBLY
SN: A80001-A80135-UP
1шт.
|$2
OR
-1шт.
|$4
714-11-10041
TRANSMISSION ASSEMBLY
SN: A80136-UP-UP
1шт.
1
TORQUE CONVERTER ASSEMBLY (SEE FIG. F4350-67A0)
SN: A80001-UP-UP
-1шт.
2
714-11-11211
CASE, FRONT
SN: A80001-UP-UP
1шт.
3
714-11-11121
CASE, TORQUE CONVERTER
SN: A80001-UP-UP
1шт.
4
04020-01228
PIN, DOWEL
SN: A80001-UP-UP
2шт.
5
01010-E1240
BOLT
SN: A80001-UP-UP
20шт.
6
01010-E1280
BOLT
SN: A80001-UP-UP
3шт.
7
01010-E1235
BOLT
SN: A80001-UP-UP
2шт.
8
01643-31232
WASHER
SN: A80001-UP-UP
5шт.
9
714-11-18311
HOUSING
SN: A80001-UP-UP
1шт.
10
714-11-18321
RETAINER
SN: A80001-UP-UP
1шт.
11
714-11-18691
GASKET
SN: A80001-UP-UP
1шт.
12
01010-E1235
BOLT
SN: A80001-UP-UP
3шт.
13
01010-E1275
BOLT
SN: A80001-UP-UP
9шт.
14
01010-E1235
BOLT
SN: A80001-UP-UP
2шт.
15
04020-01228
PIN, DOWEL
SN: A80001-UP-UP
2шт.
16
07000-15260
O-RING
SN: A80001-UP-UP
1шт.
17
07043-70211
PLUG
SN: A80001-UP-UP
3шт.
N/I
419-15-18131
LIQUID GASKET
SN: A80001-UP-UP
1шт.
18
SHIM (SEE FIG. F4350-56A0)
SN: A80001-UP-UP
-1шт.
19
PISTON - WITH PIN (SEE FIG. F4350-57A0)
SN: A80001-UP-UP
-1шт.
20
PLATE, SEPARATOR (SEE FIG. F4350-57A0)
SN: A80001-UP-UP
-1шт.
21
O-RING (SEE FIG. F4300-01A0)
SN: A80001-UP-UP
-1шт.
22
WASHER (SEE FIG. F4300-01A0)
SN: A80001-UP-UP
-1шт.
23
BOLT (SEE FIG. F4300-01A0)
SN: A80001-UP-UP
-1шт.
|$29
-1шт.
|$31
-1шт.
