|$0
417-22-20001
AXLE ASSEMBLY, FRONT - STANDARD
SN: A81001-UP-UP
1шт.
|$2
OR
-1шт.
|$4
417-22-20050
AXLE ASSEMBLY, FRONT - LIMITED SLIP
SN: A81001-UP-UP
1шт.
1
417-22-22530
GEAR
SN: A81001-UP-UP
6шт.
2
417-22-22810
BEARING
SN: A81001-UP-UP
12шт.
3
417-22-22610
CARRIER
SN: A81001-UP-UP
2шт.
4
417-22-12350
SPACER
SN: A81001-UP-UP
2шт.
5
417-22-12510
SHAFT
SN: A81001-UP-UP
6шт.
6
419-22-12570
PIN
SN: A81001-UP-UP
6шт.
7
417-22-22410
SHAFT
SN: A81001-UP-UP
2шт.
8
417-22-12540
GEAR
SN: A81001-UP-UP
2шт.
9
417-22-12580
PIN
SN: A81001-UP-UP
6шт.
10
417-22-12840
BEARING
SN: A81001-UP-UP
2шт.
11
417-22-12850
BEARING
SN: A81001-UP-UP
2шт.
12
01010-61685
BOLT
SN: A81001-UP-UP
2шт.
13
417-22-12360
SHIM - 0.002 IN. (0.05 MM)
SN: A81001-UP-UP
2шт.
|$18
417-22-12370
SHIM - 0.008 IN. (0.20 MM)
SN: A81001-UP-UP
4шт.
|$19
417-22-12380
SHIM - 0.012 IN. (0.30 MM)
SN: A81001-UP-UP
6шт.
|$20
417-22-12390
SHIM - 0.031 IN. (0.80 MM)
SN: A81001-UP-UP
2шт.
14
417-22-12460
SEAL
SN: A81001-UP-UP
2шт.
15
417-22-12421
SHAFT
SN: A81001-UP-UP
2шт.
16
417-33-11263
PLATE
SN: A81001-UP-UP
2шт.
17
417-33-11243
DISC
SN: A81001-UP-UP
2шт.
18
417-33-11290
DISC
SN: A81001-UP-UP
2шт.
19
417-33-11122
PISTON
SN: A81001-UP-UP
2шт.
20
417-33-11410
O-RING
SN: A81001-UP-UP
2шт.
21
BOLT (SEE FIG. F4400-05A0)
SN: A81001-UP-UP
-1шт.
22
WASHER (SEE FIG. F4400-05A0)
SN: A81001-UP-UP
-1шт.
